Sony VPL-FH31 Service Manual

1-26 (E)
VPL-FH31/F401H
1-3-21. In-polarizer (R)/(G)/(B) Assembly
n
When the in-polarizer (R)/(G)/(B) assembly is removed from unit assembly, perform the adjustment after
installing. (Refer to Section 2-2.)
1 Screw (B2 x 5)
2 In-polarizer (G) assembly
3 Screw (B2 x 5)
4 In-polarizer (R) assembly
5 Screw (B2 x 5)
6 In-polarizer (B) assembly
Unit assembly
