51
Specifications
Item Description
Display system SXRD panel, projection system
Display device Size of effective
display area
0.74-inch (18.8 mm) SXRD
Number of pixels 26,542,080 pixels (8,847,360 pixels × 3)
Projection lens 2.06 times zoom lens (motorized)
f = 21.7 mm to 44.7 mm
F3.0 to F4.0
Light source Ultra High Pressure Lamp 225 W type
Screen size 60 inches to 300 inches (1,524 mm to 7,620 mm)
(measured diagonally)
Accepted digital signals 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/
50i, 1080/60p, 1080/50p, 1080/24p, 3840 × 2160/24p,
3840 × 2160/25p, 3840 × 2160/30p, 3840 × 2160/50p,
3840 × 2160/60p, 4096 × 2160/24p, 4096 × 2160/25p,
4096 × 2160/30p, 4096 × 2160/50p, 4096 × 2160/60p
HDMI (2 inputs), HDCP compliant RGB
Y P
B/CB PR/CR
Other inputs/
outputs
TRIGGER
(2 connectors)
Minijack, DC 12 V Max. 100 mA
REMOTE RS-232C: D-sub 9-pin (female)
LAN RJ45, 10BASE-T/100BASE-TX
IR IN Minijack
USB DC 5 V, Max. 500 mA
Outside dimensions (w/h/d) 495.6 mm × 195.3 mm × 463.6 mm (19
1
/
2
× 7
11
/
16
×
18
1
/
4
inches) (without protrusions)
Mass Approx. 14 kg (31 lb)
Power requirements AC 100 V to 240 V, 3.5 A to 1.5 A, 50/60 Hz
Power consumption 350 W
Power consumption Standby 0.3 W (when “Remote Start” is set to “Off”)
Networked
Standby
1.0 W (LAN) (when “Remote Start” is set to “On”)
When a LAN terminal is not connected, it becomes a
low power consumption mode (0.5 W).
Operating temperature 5°C to 35°C (41°F to 95°F)
Operating humidity 35% to 85% (no condensation)
Storage temperature –20°C to +60°C (–4°F to +140°F)
Storage humidity 10% to 90%
Supplied accessories See “Checking the Supplied Accessories” in the
supplied Quick Reference Manual.
Optional accessories Projector Lamp: LMP-H220 (for replacement)
Projector Suspension Support: PSS-H10
Active 3D Glasses: TDG-BT500A
To Next Page
