Sony VPL-VW260ES - Ceiling Mount Holes

67
Holes for the ceiling mount
Use the screws with a length of 5.3 mm (
7
/
32
inches, minimum) to 7.6 mm (
5
/
16
inches,
maximum) for the ceiling mount.
Recommended tightening torque (tension when turning a screw towards the direction of
rotation): 1.4 ± 0.2 N-m
Unit: mm (inches)
Unit
Insert nut (M5)
Screw hole
The maximum
length of screw
The minimum
length of screw
