– 11 –
LEVER (N/R) ASSY, PINCH
HEAD, MAGNETIC (HP901)
1 claw
2 Remove the pinch lever (R) assy
to direction of the arrow.
4 Remove the pinch lever (N) assy
to direction of the arrow.
3 cla
w
1 claw
2 Remove the magnetic hea
to direction of the arrow.
