Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 28 —
< VARIABLE RESISTOR >
RV301 1-225-684-21 RES, VAR, CARBON 30K/30K (VOL)
RV601 1-225-254-21 RES, ADJ, CARBON 2.2K (TAPE SPEED)
< SWITCH >
S701 1-771-475-21 SWITCH, SLIDE (DIRECTION)
S702 1-771-053-21 SWITCH, KEY BOARD (p)
S703 1-771-053-21 SWITCH, KEY BOARD (9(REPEAT)
S704 1-771-053-21 SWITCH, KEY BOARD (FF)
S705 1-771-053-21 SWITCH, KEY BOARD (REW)
S707 1-572-922-11 SWITCH, SLIDE (HOLD)
< THERMISTOR >
THP601 1-810-794-11 THERMISTOR, POSITIVE 3.3K
< VIBRATOR >
X701 1-579-258-11 VIBRATOR, CRYSTAL (32.768kHz)
************************************************************
MISCELLANEOUS
**************
S901 1-762-553-11 SWITCH, LEAF
HP901 1-500-576-11 HEAD, MAGNETIC (PLAYBACK)
M901 1-763-166-11 MOTOR (CAPSTAN/REEL) (WITH PULLEY)
PM901 1-454-674-32 SOLENOID, PLUNGER
************************************************************
WM-EX678
Sony Corporation
Personal A&V Products Company
99A1651-1
Printed in Singapore © 1999.1
Published by Quality Engineering Dept.
(Shibaura)
9-926-931-11
ACCESSORIES
***********
1-418-021-11 REMOTE CONTROL UNIT (RM-WME21)
! 1-528-252-21 BATTERY CHARGER (BC-7S)(UK)
1-528-543-22 BATTERY, NI-CD (NC-6WM)
! 1-528-744-23 BATTERY CHARGER (BC-7DY)(AEP,FR,EE)
1-759-700-21 CASE, BATTERY
3-008-521-01 CASE, BATTERY CHARGE
3-029-488-01 POUCH, CARRYING
3-864-887-11 MANUAL, INSTRUCTION (ENGLISH/FRENCH)
3-864-887-21 MANUAL, INSTRUCTION (GERMAN/DUTCH)
(AEP)
3-864-887-31 MANUAL, INSTRUCTION (SWEDISH/ITALIAN)
(AEP)
3-864-887-41 MANUAL, INSTRUCTION
(SPANISH/PORTUGUESE) (AEP)
3-864-887-51 MANUAL, INSTRUCTION (FINNISH/RUSSIAN)
(AEP,EE)
3-864-887-61 MANUAL, INSTRUCTION (POLISH/CZECH) (EE)
8-953-272-90 HEADPHONE MDR-ED136SP//K SET
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
