Sony Walkman WM-EX678 Service Manual

— 4 —
[ Slider (NR) ] [ Tape drive mechanism ]
Tape drive mechanism in PLAY mode
Tape drive mechanism in FF mode Tape drive mechanism in REW mode
Slider (NR)
Center
F side
R side
Insert Flywheel (N)
Pulley (Reverse)
Clutch Assy
Motor Pulley
Gear (REEL)(S side)
Gear
(REEL)(T side)
Gear (NR)
(FWD : Left side
REV : Right side)
Idler Gear
Idler Gear (A)(S side)
Idler Gear
(A)(T side)
Insert Flywheel (R)
Cam Gear
Gear (Y)
Insert Flywheel (N)
Pulley (Reverse)
Clutch Assy
Motor Pulle
y
Gear
(REEL)(T side)
Idler Gear
(A)(T side)
Insert Flywheel (R)
Cam Gear
Gear (Y)
Gear (FR)
(FF : Left side)
Insert Flywheel (N)
Pulley (Reverse)
Clutch Assy
Motor Pulley
Gear
(REEL)(S side)
Idler Gear
(A)(S side)
Insert Flywheel (R)
Cam Gear
Gear (Y)
Gear (FR)
(REW : Right side)
