– 28 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
IC703 8-759-438-27 IC MM1305BWBE
IC704 8-759-572-21 IC S-80808ANNP-E7Y-T2
IC705 8-759-833-30 IC ML63514-024TBZ060
< JACK >
J301 1-779-867-81 JACK (i)
< SHORT >
JC101 1-218-990-11 SHORT 0
JC102 1-218-990-11 SHORT 0
JC201 1-218-990-11 SHORT 0
JC202 1-218-990-11 SHORT 0
JC701 1-218-990-11 SHORT 0
< COIL >
L701 1-412-034-11 INDUCTOR 330uH
< PHOTO REFLECTOR >
PH701 8-749-016-56 REFLECTOR NJL5197K-W-F20 (TE1)
PH702 8-749-016-56 REFLECTOR NJL5197K-W-F20 (TE1)
< TRANSISTOR >
Q301 8-729-425-46 TRANSISTOR XP4315-TXE
Q302 8-729-426-36 TRANSISTOR XP1215-TXE
Q304 8-729-426-36 TRANSISTOR XP1215-TXE
Q305 8-729-038-06 TRANSISTOR HN1K02FU (TE85L)
Q306 8-729-037-63 TRANSISTOR UN9115J- (TX). SO
Q309 8-729-053-70 TRANSISTOR 2SA202800LS0
Q311 8-729-038-06 TRANSISTOR HN1K02FU (TE85L)
Q312 8-729-230-63 TRANSISTOR 2SC4116-YG
Q314 8-729-230-63 TRANSISTOR 2SC4116-YG
Q315 8-729-038-06 TRANSISTOR HN1K02FU (TE85L)
Q316 8-729-046-89 TRANSISTOR 2SB970-S (TX). S0
Q317 8-729-426-36 TRANSISTOR XP1215-TXE
Q601 8-729-043-94 TRANSISTOR CPH3106-PM-TL
Q602 8-729-420-24 TRANSISTOR 2SB1218A-QRS
Q603 8-729-039-36 TRANSISTOR MDC06TR
Q701 8-729-046-89 TRANSISTOR 2SB970-S (TX). S0
Q702 8-729-037-63 TRANSISTOR UN9115J- (TX). SO
Q703 8-729-427-51 TRANSISTOR XP4215-TXE
< RESISTOR >
R101 1-218-967-11 RES-CHIP 15K 5% 1/16W
R102 1-218-943-11 RES-CHIP 150 5% 1/16W
R103 1-218-977-11 RES-CHIP 100K 5% 1/16W
R104 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R105 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R107 1-218-953-11 RES-CHIP 1K 5% 1/16W
R108 1-218-969-11 RES-CHIP 22K 5% 1/16W
R109 1-244-161-81 RES-CHIP 2.2 5% 1/16W
R111 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R112 1-218-971-11 RES-CHIP 33K 5% 1/16W
R113 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R114 1-218-989-11 RES-CHIP 1M 5% 1/16W
R116 1-218-973-11 RES-CHIP 47K 5% 1/16W
R117 1-218-943-11 RES-CHIP 150 5% 1/16W
R201 1-218-967-11 RES-CHIP 15K 5% 1/16W
R202 1-218-943-11 RES-CHIP 150 5% 1/16W
R203 1-218-977-11 RES-CHIP 100K 5% 1/16W
R204 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R205 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R207 1-218-953-11 RES-CHIP 1K 5% 1/16W
R208 1-218-969-11 RES-CHIP 22K 5% 1/16W
R209 1-244-161-81 RES-CHIP 2.2 5% 1/16W
R211 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R212 1-218-971-11 RES-CHIP 33K 5% 1/16W
R213 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R214 1-218-989-11 RES-CHIP 1M 5% 1/16W
R216 1-218-973-11 RES-CHIP 47K 5% 1/16W
R217 1-218-943-11 RES-CHIP 150 5% 1/16W
R301 1-218-981-11 RES-CHIP 220K 5% 1/16W
R302 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R303 1-218-985-11 RES-CHIP 470K 5% 1/16W
R306 1-218-983-11 RES-CHIP 330K 5% 1/16W
R308 1-220-803-81 RES-CHIP 4.7 5% 1/16W
R309 1-218-971-11 RES-CHIP 33K 5% 1/16W
R310 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R312 1-218-969-11 RES-CHIP 22K 5% 1/16W
R313 1-208-939-11 METAL CHIP 150K 0.5% 1/16W
R314 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R316 1-218-985-11 RES-CHIP 470K 5% 1/16W
R317 1-218-985-11 RES-CHIP 470K 5% 1/16W
R318 1-218-941-11 RES-CHIP 100 5% 1/16W
R319 1-218-969-11 RES-CHIP 22K 5% 1/16W
R320 1-218-985-11 RES-CHIP 470K 5% 1/16W
R601 1-218-973-11 RES-CHIP 47K 5% 1/16W
R602 1-218-973-11 RES-CHIP 47K 5% 1/16W
R603 1-218-969-11 RES-CHIP 22K 5% 1/16W
R604 1-218-977-11 RES-CHIP 100K 5% 1/16W
R605 1-218-985-11 RES-CHIP 470K 5% 1/16W
R606 1-218-981-11 RES-CHIP 220K 5% 1/16W
R607 1-218-979-11 RES-CHIP 150K 5% 1/16W
R608 1-218-977-11 RES-CHIP 100K 5% 1/16W
R609 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R610 1-218-977-11 RES-CHIP 100K 5% 1/16W
R611 1-218-983-11 RES-CHIP 330K 5% 1/16W
R612 1-218-989-11 RES-CHIP 1M 5% 1/16W
R613 1-218-989-11 RES-CHIP 1M 5% 1/16W
R614 1-218-977-11 RES-CHIP 100K 5% 1/16W
R701 1-218-935-11 RES-CHIP 33 5% 1/16W
R702 1-218-977-11 RES-CHIP 100K 5% 1/16W
R703 1-218-971-11 RES-CHIP 33K 5% 1/16W
R704 1-218-971-11 RES-CHIP 33K 5% 1/16W
R705 1-218-973-11 RES-CHIP 47K 5% 1/16W
R706 1-208-711-11 METAL CHIP 15K 0.5% 1/16W
R707 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R708 1-218-985-11 RES-CHIP 470K 5% 1/16W
R709 1-218-977-11 RES-CHIP 100K 5% 1/16W
R710 1-218-985-11 RES-CHIP 470K 5% 1/16W
R711 1-218-973-11 RES-CHIP 47K 5% 1/16W
R712 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R713 1-218-987-11 RES-CHIP 680K 5% 1/16W
R714 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R715 1-218-987-11 RES-CHIP 680K 5% 1/16W
R716 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
