— 35 —
REF. No. Part No. Description Remark
REF. No. Part No. Description Remark
TUNER
C82 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< FILTER >
CF1 1-579-974-11 FILTER, CERAMIC
CF2 1-579-823-21 FILTER, CERAMIC
CF3 1-567-248-11 FILTER, CERAMIC
CF4 1-579-974-11 FILTER, CERAMIC
< TRIMMER >
CT1 1-141-327-11 CAP, VAR, TRIMMER (CHIP TYPE)
< DIODE >
D1 8-719-050-97 DIODE MA357(E)-(TX).SO
D2 8-719-050-97 DIODE MA357(E)-(TX).SO
D3 8-719-055-61 DIODE HVR100-9TRU
D4 8-719-055-61 DIODE HVR100-9TRU
D5 8-719-420-87 DIODE MA8130
D6 8-719-404-46 DIODE MA110
D7 8-719-420-51 DIODE MA729
< IC >
IC1 8-759-362-23 IC TA7371AF-EL
IC2 8-759-362-25 IC TA-2022AFN-EL
IC3 8-759-362-24 IC TC9418FN-EL
IC4 8-759-524-74 IC S-29L194-S
IC5 8-759-186-88 IC TA2015FN-EL
< JUMPER RESISTOR >
JC1 1-216-295-91 CONDUCTOR, CHIP (2012)
JC2 1-216-864-11 METAL CHIP 0 5% 1/16W
JC3 1-216-864-11 METAL CHIP 0 5% 1/16W
JC4 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L3 1-409-837-11 COIL (WITH CORE) (IF)
L4 1-412-010-41 INDUCTOR CHIP 22uH
L5 1-501-812-11 ANTENNA, FERRITE-ROD
L7 1-410-213-51 INDUCTOR CHIP 56uH
L8 1-412-032-11 INDUCTOR CHIP 100uH
L9 1-412-029-11 INDUCTOR CHIP 10uH
< TRANSISTOR >
Q1 8-729-425-73 TRANSISTOR 2SC4627-C
Q2 8-729-425-73 TRANSISTOR 2SC4627-C
Q3 8-729-823-86 TRANSISTOR 2SA1745
Q4 8-729-425-73 TRANSISTOR 2SC4627-C
Q5 8-729-425-73 TRANSISTOR 2SC4627-C
Q6 8-729-429-32 TRANSISTOR UN9210-QRS
Q7 8-729-028-69 TRANSISTOR 2SC4655-BC(TX)
Q8 8-729-028-69 TRANSISTOR 2SC4655-BC(TX)
Q9 8-729-425-73 TRANSISTOR 2SC4627-C
Q10 8-729-428-93 TRANSISTOR UN9115-QRS-(TXE)
Q11 8-729-429-32 TRANSISTOR UN9210-QRS
Q12 8-729-429-32 TRANSISTOR UN9210-QRS
Q13 8-729-429-32 TRANSISTOR UN9210-QRS
Q14 8-729-429-32 TRANSISTOR UN9210-QRS
Q15 8-729-428-93 TRANSISTOR UN9115-QRS-(TXE)
Q16 8-729-428-93 TRANSISTOR UN9115-QRS-(TXE)
Q17 8-729-429-32 TRANSISTOR UN9210-QRS
Q18 8-729-429-32 TRANSISTOR UN9210-QRS
Q19 8-729-428-93 TRANSISTOR UN9115-QRS-(TXE)
Q20 8-729-800-37 TRANSISTOR 2SD1048-X7
Q21 8-729-420-68 TRANSISTOR 2SD1328-R-TX
Q22 8-729-807-88 TRANSISTOR 2SB1295-UL7
Q23 8-729-807-88 TRANSISTOR 2SB1295-UL7
Q24 8-729-807-87 TRANSISTOR 2SB1295-UL6
Q25 8-729-028-69 TRANSISTOR 2SC4655-BC(TX)
Q26 8-729-428-93 TRANSISTOR UN9115-QRS-(TXE)
Q27 8-729-028-69 TRANSISTOR 2SC4655-BC(TX)
Q28 8-729-428-93 TRANSISTOR UN9115-QRS-(TXE)
Q29 8-729-429-32 TRANSISTOR UN9210-QRS
Q30 8-729-028-69 TRANSISTOR 2SC4655-BC(TX)
Q31 8-729-428-93 TRANSISTOR UN9115-QRS
< RESISTOR >
R1 1-216-821-11 METAL CHIP 1K 5% 1/16W
R2 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R3 1-216-853-11 METAL CHIP 470K 5% 1/16W
R4 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5 1-216-818-11 METAL CHIP 560 5% 1/16W
R6 1-216-833-11 METAL CHIP 10K 5% 1/16W
R7 1-216-853-11 METAL CHIP 470K 5% 1/16W
R8 1-216-853-11 METAL CHIP 470K 5% 1/16W
R9 1-216-833-11 METAL CHIP 10K 5% 1/16W
R10 1-216-821-11 METAL CHIP 1K 5% 1/16W
R11 1-216-849-11 METAL CHIP 220K 5% 1/16W
R12 1-216-821-11 METAL CHIP 1K 5% 1/16W
R13 1-216-845-11 METAL CHIP 100K 5% 1/16W
R14 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R15 1-216-809-11 METAL CHIP 100 5% 1/16W
R16 1-216-833-11 METAL CHIP 10K 5% 1/16W
R17 1-216-833-11 METAL CHIP 10K 5% 1/16W
R18 1-216-853-11 METAL CHIP 470K 5% 1/16W
R19 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R20 1-216-845-11 METAL CHIP 100K 5% 1/16W
R21 1-216-837-11 METAL CHIP 22K 5% 1/16W
R22 1-216-833-11 METAL CHIP 10K 5% 1/16W
R23 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R24 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R25 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
Ver 1.1 2002.01
