Setup Menu List
103
Menu Configuration and Detailed Settings
LCD/VF SET Menu
LCD/VF SET
Menu items Subitems and setting values Contents
LCD
Adjusting the LCD
monitor
Color
–99 to +99 (±0)
Adjust the color of pictures on the LCD monitor.
Contrast
–99 to +99 (±0)
Adjust the contrast of pictures on the LCD monitor.
Brightness
–99 to +99 (±0)
Adjust the brightness of pictures on the LCD monitor.
EVF
Setting the
viewfinder
Backlight
High / Low
Select the brightness of the EVF backlight.
Mode
Color / B&W
Select the display mode of the EVF.
Color: Color mode
B&W: Monochrome mode
Contrast
–99 to +99 (±0)
Adjust the contrast of pictures on the EVF screen.
Brightness
–99 to +99 (±0)
Adjust the brightness of pictures on the EVF screen.
Power
Auto / On
Set the condition to turn the EVF on.
Auto: To turn it on when the LCD monitor is closed or rotated
to the upside-down position.
On: To keep it on regardless of the status of the LCD monitor
Peaking
Setting the peaking
function for the
LCD monitor/EVF
Color
White / Red / Yellow / Blue
Select the color of the peaking signal.
Level
High / Mid / Low
Set the level of the peaking signal.
Marker
Setting the
markers added to
pictures on the
LCD monitor/EVF
screen
Setting
On / Off
Turn all marker indications on/off in combination.
Safety Zone
On / Off
Turn the safety marker on/off.
Safety Area
80% / 90% / 92.5% / 95%
Select the size (ratio to the entire screen) of the safety zone
marker.
Center Marker
On / Off
Turn the center marker on/off.
Aspect Marker
On / Off
Turn the aspect marker on/off.
Aspect Select
4:3 / 13:9 / 14:9 / 15:9
Select the type of the aspect marker.
Guide Frame
On / Off
Turn the guide frame marker on/off.
Zebra
Setting the zebra
pattern
Zebra Select
1 / 2 / Both
Select the zebra pattern(s) to be displayed.
1: To display zebra 1 only
2: To display zebra 2 only
Both: To display both zebra 1 and zebra 2.
Zebra1 level
50 to 107 (70)
Set the display level of zebra 1.
