VIDEO Status Screen / BUTTON/REMOTE Status Screen
91
Status Displays
The information on video formats and settings for
the COMPONENT OUT, SDI OUT, A/V OUT,
i.LINK connectors is displayed.
Video Format: Video format setting
The picture size (effective vertical lines), frame
rate, and scan format set in “Video Format” of the
OTHERS menu are displayed.
Rec Mode: Recording bit rate
The bit rate (HQ or SP) set in “Video Format” of
the OTHERS menu is displayed.
YPbPr/SDI Out: Component and SDI output status
The picture size (effective vertical lines), frame
rate, and scan format of the signal being fed from
the COMPONENT OUT and SDI OUT
connectors according to the “YPbPr/SDI Out
Select” setting of the VIDEO SET menu are
displayed.
Video Out: Output status of the A/V OUT
connector
“Off” is displayed when “YPbPr/SDI Out Select”
of the VIDEO SET menu is set to “HD” or “SD.”
The format (NTSC or PAL) of the analog com-
posite signal being fed from the A/V OUT con-
nector is displayed when “YPbPr/SDI Out
Select” of the VIDEO SET menu is set to “Off.”
Down Converter: Down-converter setting of the
SD output
The “Down Converter” setting (Squeeze, Edge
Crop, Letterbox) of the VIDEO SET menu is
displayed.
i.LINK I/O: i.LINK I/O status
The i.LINK I/O setting (Enable /Disable) of the
OTHERS menu is displayed.
The functions assigned to the assignable buttons
and the status of the IR Remote Commander are
displayed.
Assign Button: Assignable button statuses
The functions assigned with the “Assign Button”
of the OTHERS menu to the respective
assignable buttons are displayed.
IR Remote: IR Remote Commander status
The status (On: enabled, Off: disabled) of the IR
Remote Commander is displayed
VIDEO Status Screen
Video
For
m
at
Rec
M
ode
YP
b
P
r/
SD
I
O
ut
Video
O
ut
D
o
w
n
C
onver ter
i.
L
I
NK
I/
O
:
1080/60i
:
HQ
:
1080/60i
:
O
ff
:
Squeeze
:
Disable
VIDEO 3 / 5
BUTTON/REMOTE Status
Screen
Assign
But ton
1:
Freeze
M
ix
2:
O
ff
3:
O
ff
4:
Rec
Review
IR
Re
m
ote
:
O
n
BUTTON / RE
M
OTE 4 / 5
