Sony XDCAM EX PMW-EX1 User Manual

Table of Contents
7
Connecting External Devices
Connecting External Monitors ............................................ 109
Operating Clips With a Computer ...................................... 110
Connecting an External Device (i.LINK Connection) ....... 113
Recording the Camcorder Picture on an External
Device .................................................................. 113
Nonlinear Editing ....................................................... 113
Recording External Input Signals .............................. 114
Appendixes
Important Notes on Operation ............................................ 115
Formats and Limitations of Outputs .................................. 116
Video Formats and Output Formats ........................... 116
Limitations of Outputs ............................................... 117
Backup Battery ..................................................................... 118
Troubleshooting .................................................................... 119
Operating Power ......................................................... 119
Recording/Playback ................................................... 119
External Devices ........................................................ 120
Error/Warning Indications .................................................. 121
Error Indications ......................................................... 121
Warning Indications ................................................... 121
About i.LINK ........................................................................ 123
Specifications ......................................................................... 124
General ....................................................................... 124
Camera Block ............................................................. 124
Audio Block ............................................................... 125
Displays ...................................................................... 125
Inputs/Outputs ............................................................ 125
Optional Accessories .................................................. 126
Index ....................................................................................... 128

Sony XDCAM EX PMW-EX1 Specifications

General

Effective Pixels	1920 x 1080
Maximum Aperture	f/1.9
Optical Zoom	14x
Recording Format	MPEG-2 Long GOP
Audio Format	Linear PCM
Video Output	HD-SDI, HDMI, Component, Composite
Image Sensor	3x 1/2-inch CMOS
Lens	Fujinon HD Zoom Lens
Focal Length	5.8-81.2 mm
Recording Media	SxS Memory Card
Video Resolution	1920 x 1080, 1280 x 720
Frame Rates	23.98p, 25p, 29.97p, 50i, 59.94i
Audio	2-Channel
LCD Screen	3.5-inch
Viewfinder	Color LCD
Input/Output	XLR Audio Inputs, USB
Battery Type	Lithium-Ion
Weight	2.4 kg (body only)
