Ref. No. Part No. Description RemarkRef. No. Part No. Description Remark
L-CH AMP LED R-CH AMP
< TRANSFORMER >
T101 1-431-185-11 TRANSFORMER, CONVERTER
T102 1-431-186-11 TRANSFORMER, DC-DC CONVERTER
< THERMISTOR >
TH101 1-808-779-11 THERMISTOR
< THERMISTOR(POSITIVE) >
THP101 1-809-664-51 THERMISTOR, POSITIVE
THP102 1-809-664-21 THERMISTOR, POSITIVE
< VARIABLE RESISTOR >
VR101 1-225-433-11 RES, VAR, CARBON 50K (LEVEL)
VR102 1-225-430-11 RES, ADJ 5K
************************************************************
* 1-664-788-11 LED BOARD
*********
< JACK >
* CNJ105 1-506-999-11 PIN, CONNECTOR (PC BOARD) 3P
* CNJ205 1-506-999-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D110 8-719-989-31 DIODE GL9ED4 (POWER/PROTECTOR LEFT)
D210 8-719-989-31 DIODE GL9ED4 (POWER/PROTECTOR RIGHT)
************************************************************
* A-3309-900-A R-CH AMP BOARD, COMPLETE
*************************
* 3-012-269-01 PLATE, SHIELD
* 3-012-270-01 BRACKET (VR)
7-685-546-14 SCREW +BTP 3X8 TYPE2 N-S
< CAPACITOR >
C201 1-107-611-11 MICA 100PF 5% 500V
C202 1-107-597-11 MICA 22PF 5% 500V
C203 1-164-732-11 CERAMIC 0.1uF 20% 50V
C204 1-164-732-11 CERAMIC 0.1uF 20% 50V
C205 1-124-724-11 ELECT 47uF 20% 50V
C206 1-136-960-11 FILM 0.1uF 10% 160V
C207 1-104-664-11 ELECT 47uF 20% 10V
C208 1-104-539-11 FILM CHIP 0.001uF 5% 50V
C209 1-136-161-00 FILM 0.047uF 5% 50V
C210 1-136-173-00 FILM 0.47uF 5% 50V
C211 1-104-539-11 FILM CHIP 0.001uF 5% 50V
C212 1-164-732-11 CERAMIC 0.1uF 20% 50V
C213 1-124-999-11 ELECT 2200uF 20% 10V
C214 1-136-961-11 FILM 0.047uF 10% 160V
C215 1-126-055-11 ELECT 470uF 20% 50V
C216 1-126-055-11 ELECT 470uF 20% 50V
C219 1-117-711-11 ELECT 6800uF 20% 25V
C220 1-117-711-11 ELECT 6800uF 20% 25V
C221 1-136-962-11 FILM 0.47uF 10% 160V
C222 1-117-712-11 ELECT 4200uF 20% 35V
C223 1-117-712-11 ELECT 4200uF 20% 35V
C224 1-117-712-11 ELECT 4200uF 20% 35V
C225 1-117-712-11 ELECT 4200uF 20% 35V
C226 1-164-732-11 CERAMIC 0.1uF 20% 50V
C227 1-164-732-11 CERAMIC 0.1uF 20% 50V
C228 1-136-153-00 FILM 0.01uF 5% 50V
C229 1-126-933-11 ELECT 100uF 20% 16V
C230 1-130-471-00 MYLAR 0.001uF 5% 50V
C231 1-124-583-11 ELECT 22uF 20% 50V
C232 1-126-933-11 ELECT 100uF 20% 16V
C233 1-124-583-11 ELECT 22uF 20% 50V
C234 1-104-539-11 FILM CHIP 0.001uF 5% 50V
C235 1-130-471-00 MYLAR 0.001uF 5% 50V
C236 1-104-539-11 FILM CHIP 0.001uF 5% 50V
C297 1-136-153-00 FILM 0.01uF 5% 50V
C298 1-136-153-00 FILM 0.01uF 5% 50V
C299 1-126-044-11 ELECT 1uF 20% 50V
< CONNECTOR >
* CN201 4-924-264-31 TERMINAL, MOUNT
* CN202 4-924-264-31 TERMINAL, MOUNT
* CN203 4-924-264-31 TERMINAL, MOUNT
* CN204 4-924-264-31 TERMINAL, MOUNT
* CN205 4-924-264-31 TERMINAL, MOUNT
* CN206 4-924-264-31 TERMINAL, MOUNT
CN207 1-694-245-11 TERMINAL BOARD (2P)
CN208 1-694-245-11 TERMINAL BOARD (2P)
* CNP201 1-779-455-11 PIN, CONNECTOR (PC BOARD) 2P
CNP202 1-506-944-21 PIN, CONNECTOR 2P
* CNP203 1-506-984-11 PIN, CONNECTOR (PC BOARD) 2P
* CNP205 1-506-985-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D201 8-719-310-60 DIODE SEL1510C-C
D202 8-719-801-78 DIODE 1SS184
D203 8-719-210-30 DIODE F10P20F(R)
D204 8-719-210-38 DIODE F10P20FR
D205 8-719-210-25 DIODE C25P20F
D206 8-719-210-26 DIODE C25P20FR
D207 8-719-984-08 DIODE HZM18NB2-TL
D208 8-719-025-34 DIODE 02CZ6.8-TE85L
D209 8-719-981-14 DIODE HZM10NB1TL
D211 8-719-801-78 DIODE 1SS184
< FERRITE BEAD >
FB201 1-410-396-41 FERRITE BEAD INDUCTOR
FB202 1-410-396-41 FERRITE BEAD INDUCTOR
FB203 1-410-396-41 FERRITE BEAD INDUCTOR
< TARMINAL >
FJ201 1-537-479-21 TERMINAL
FJ202 1-537-479-21 TERMINAL
< IC >
IC201 8-759-701-59 IC NJM78M09FA
IC202 8-759-144-88 IC uPC494GS
