– 2 –
TABLE OF CONTENTS
1. GENERAL
Location of Controls ....................................................... 3
Setting the Clock ............................................................. 3
Labelling the Rotary Commander .................................. 4
Using the Rotary Commander ........................................ 4
Installation ....................................................................... 5
Connection ...................................................................... 6
2. DISASSEMBLY ......................................................... 8
3. ASSEMBLY OF MECHANISM DECK........... 10
4. MECHANICAL ADJUSTMENTS ....................... 13
5. ELECTRICAL ADJUSTMENTS
Test Mode ........................................................................ 13
Tape Deck Section .......................................................... 13
Tuner Section .................................................................. 14
6. DIAGRAMS
6-1. Printed Wiring Boards – Main Section – (Side A)....... 17
Printed Wiring Boards – Main Section – (Side B)....... 19
6-2. Schematic Diagram – Main (1/2) Section – ................... 21
6-3. Schematic Diagram – Main (2/2) Section – ................... 23
6-4. Printed Wiring Board – Panel Section –
(Side A), (Side B) ............................................................ 25
6-5. Schematic Diagram – Panel Section – .......................... 27
6-6. IC Pin Function Description ........................................... 32
7. EXPLODED VIEWS ................................................ 35
8. ELECTRICAL PARTS LIST ............................... 38
Flexible Circuit Board Repairing
Keep the temperature of the soldering iron around 270 ˚C dur-
ing repairing.
Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
Be careful not to apply force on the conductor when soldering
or unsoldering.
Notes on chip component replacement
Never reuse a disconnected chip component.
Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
