Sony XR-C5200 Service Manual

– 38 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R965 1-216-033-00 METAL CHIP 220 5% 1/10W
R967 1-216-033-00 METAL CHIP 220 5% 1/10W
R969 1-216-033-00 METAL CHIP 220 5% 1/10W
R975 1-216-029-00 METAL CHIP 150 5% 1/10W
R977 1-216-037-00 METAL CHIP 330 5% 1/10W
R981 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R982 1-216-663-11 METAL CHIP 3.3K 0.5% 1/10W
R983 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R984 1-216-081-00 METAL CHIP 22K 5% 1/10W
R990 1-216-295-00 SHORT 0
R991 1-216-295-00 SHORT 0
R999 1-216-295-00 SHORT 0
< ROTARY ENCODER >
RE901 1-475-014-11 ENCODER, ROTARY (VOLUME/BASS/TREBLE/
BALANCE/FADER CONTROL)
< SWITCH >
S901 1-771-290-11 SWITCH, SLIDE
(SEEK/AMS + + ), – = 0)
S981 1-762-937-11 SWITCH, ROTARY (D-BASS)
************************************************************
* A-3317-520-A MAIN BOARD, COMPLETE
*********************
* 3-018-390-01 BRACKET (IC)
* 3-031-023-11 HEAT SINK
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-794-09 SCREW +PTT 2.6X10 (S)
< CAPACITOR >
C1 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C2 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C3 1-124-234-00 ELECT 22uF 20% 16V
C4 1-124-233-11 ELECT 10uF 20% 16V
C5 1-124-234-00 ELECT 22uF 20% 16V
C6 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C7 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C8 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C9 1-163-205-00 CERAMIC CHIP 0.001uF 5% 50V
C10 1-163-205-00 CERAMIC CHIP 0.001uF 5% 50V
C11 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C12 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C21 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C22 1-163-133-00 CERAMIC CHIP 470uF 5% 50V
C23 1-124-234-00 ELECT 22uF 20% 16V
C24 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C25 1-163-091-00 CERAMIC CHIP 8PF 50V
C26 1-124-233-11 ELECT 10uF 20% 16V
C27 1-163-224-11 CERAMIC CHIP 7PF 0.5PF 50V
C28 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C29 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C30 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C31 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C32 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C33 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C34 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C35 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C36 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C37 1-124-233-11 ELECT 10uF 20% 16V
C38 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C39 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C40 1-163-224-11 CERAMIC CHIP 7PF 0.5% 50V
C41 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C44 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C45 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C51 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C52 1-124-233-11 ELECT 10uF 20% 16V
C53 1-124-234-00 ELECT 22uF 20% 16V
C54 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C55 1-124-234-00 ELECT 22uF 20% 16V
C56 1-124-234-00 ELECT 22uF 20% 16V
C101 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C102 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C103 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C104 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C105 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C106 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C107 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C108 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C109 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C110 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C111 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C121 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C122 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C124 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C141 1-165-320-11 CERAMIC CHIP 0.47uF 10% 16V
C142 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C151 1-163-018-00 CERAMIC CHIP 0.0056uF 10% 50V
C152 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C153 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C171 1-126-163-11 ELECT 4.7uF 20% 50V
C172 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C174 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C181 1-126-163-11 ELECT 4.7uF 20% 50V
C182 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C183 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C184 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C191 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C201 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C202 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C203 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C204 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C205 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C206 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C207 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C208 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C209 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C210 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C211 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C241 1-165-320-11 CERAMIC CHIP 0.47uF 10% 16V
C242 1-163-181-00 CERAMIC CHIP 100PF 5% 50V
C251 1-163-018-00 CERAMIC CHIP 0.0056uF 10% 50V
C252 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C253 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C271 1-126-163-11 ELECT 4.7uF 20% 50V
KEY MAIN
