Sony XR-C5200 Service Manual

– 39 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C272 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C274 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C281 1-126-163-11 ELECT 4.7uF 20% 50V
C282 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C283 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C284 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C301 1-124-234-00 ELECT 22uF 20% 16V
C303 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C304 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C305 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C306 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C307 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C333 1-124-233-11 ELECT 10uF 20% 16V
C334 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C335 1-124-584-00 ELECT 100uF 20% 10V
C336 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C337 1-124-234-00 ELECT 22uF 20% 16V
C351 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C352 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C353 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C354 1-124-233-11 ELECT 10uF 20% 16V
C355 1-124-234-00 ELECT 22uF 20% 16V
C356 1-126-934-11 ELECT 220uF 20% 16V
C357 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C358 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C501 1-124-584-00 ELECT 100uF 20% 10V
C502 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C503 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C504 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C505 1-163-234-11 CERAMIC CHIP 20PF 5% 50V
C506 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C507 1-163-051-11 CERAMIC CHIP 0.0022uF 10% 50V
C508 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C551 1-125-710-11 DOUBLE LAYER 0.1F 5.5V
C552 1-128-057-11 ELECT 330uF 20% 6.3V
C553 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C556 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C571 1-126-163-11 ELECT 4.7uF 20% 50V
C581 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C582 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C583 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C584 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C601 1-164-346-11 CERAMIC CHIP 1uF 16V
C602 1-164-346-11 CERAMIC CHIP 1uF 16V
C611 1-124-233-11 ELECT 10uF 20% 16V
C612 1-124-233-11 ELECT 10uF 20% 16V
C614 1-124-233-11 ELECT 10uF 20% 16V
C615 1-124-233-11 ELECT 10uF 20% 16V
C616 1-124-233-11 ELECT 10uF 20% 16V
C617 1-124-233-11 ELECT 10uF 20% 16V
C618 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C621 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C622 1-124-589-11 ELECT 47uF 20% 16V
C623 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C751 1-128-076-11 ELECT 10uF 20% 25V
C752 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C754 1-124-233-11 ELECT 10uF 20% 16V
C755 1-124-589-11 ELECT 47uF 20% 16V
C757 1-124-233-11 ELECT 10uF 20% 16V
C781 1-126-936-11 ELECT 3300uF 20% 16V
C782 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C783 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C784 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C785 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C786 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C787 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C788 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C789 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C790 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C792 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C795 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C993 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN301 1-766-260-11 CONNECTOR, FFC/FPC (ZIF) 7P
* CN351 1-506-995-11 PIN, CONNECTOR (PC BOARD) 13P
CN581 1-580-907-31 PLUG, CONNECTOR (BUS CONTROL IN)
CN701 1-785-774-11 PLUG, CONNECTOR 15P
CN781 1-774-701-11 PIN, CONNECTOR 16P (POWER)
< DIODE >
D1 8-719-991-65 DIODE SB02W03C
D51 8-719-158-15 DIODE RD5.6S-B
D52 8-719-423-10 DIODE MA8100-M-TX
D351 8-719-977-22 DIODE DTZ9.1
D352 8-719-911-19 DIODE 1SS119
D501 8-719-400-20 DIODE MA152WA
D551 8-719-400-20 DIODE MA152WA
D552 8-719-404-50 DIODE MA111-TX
D553 8-719-404-50 DIODE MA111-TX
D554 8-719-072-70 DIODE MA2ZD14001S0
D571 8-719-057-80 DIODE MA8160-M-TX
D572 8-719-420-14 DIODE MA8082-M
D581 8-719-057-80 DIODE MA8160-M-TX
D582 8-719-017-62 DIODE MA8068-L-TX
D583 8-719-105-99 DIODE RD6.2M-B1
D584 8-719-057-80 DIODE MA8160-M-TX
D585 8-719-072-70 DIODE MA2ZD14001S0
D586 8-719-057-80 DIODE MA8160-M-TX
D587 8-719-404-50 DIODE MA111-TX
D588 8-719-404-50 DIODE MA111-TX
D601 8-719-423-32 DIODE MA8120-M
D610 8-719-970-02 DIODE 1SR139-400
D611 8-719-970-02 DIODE 1SR139-400
D613 8-719-970-02 DIODE 1SR139-400
D614 8-719-970-02 DIODE 1SR139-400
D621 8-719-422-12 DIODE MA8039
D622 8-719-404-50 DIODE MA111-TX
D623 8-719-422-12 DIODE MA8039
D624 8-719-422-97 DIODE MA8091-M
D701 8-719-977-12 DIODE DTZ6.8B
D702 8-719-158-15 DIODE RD5.6S-B
D704 8-719-158-15 DIODE RD5.6S-B
D705 8-719-035-74 DIODE MA4062-M (TA)
D706 8-719-035-74 DIODE MA4062-M (TA)
D707 8-719-035-74 DIODE MA4062-M (TA)
MAIN
