492
a) 1: R1, 2: G1, 3: R2, 4: G2, 5: R3, 6: G3, 7: R4, 8: G4, 9: R5, 10: G5,
11: R6, 12: G6, 13: R7, 14: G7, 15: R8, 16: G8 (R stands for Red
Tally, and G for Green Tally)
7
Press [Execute].
Deleting Parallel Tally
1
In the Engineering Setup >Router/Tally >Parallel
Tally menu (7366), select the parallel tally.
2
Press [Clear].
Serial Tally Settings
You can configure the tally type, data size, and source
address for two serial tally ports on a system interface unit
(SIU). You can also specify a port number for a network
connection to control tally information via a network.
If using a network port, configuration of the SIU utility
connector is required. For details, refer to the ICP-X7000
Installation Manual.
Configuring/Modifying Serial Tally
1
In the <Serial Tally Port> of the Engineering Setup
>Router/Tally >Serial Tally menu (7367), select the
target port to set.
2
In the <Tally Group> group, select the tally group.
3
In the <Tally Type> group, select the tally types.
Up to four tally types can be selected.
The selectable tally types depend on the setting
selected in step 2.
4
In the <Tally Data Size> group, select the data size.
128 Bit: 128 bits
256 Bit: 256 bits
5
To configure a network port, select [Port].
Enter the network port number using the numeric
keypad window, then press [Enter].
Correct operation may not occur, depending on the
port.
For the serial tally network port, port number “2020”
is recommended for [Port1], and “2021” is
recommended for [Port2]. For details, consult your
Sony service or sales representative.
No. Parameter Adjustment
3 Type Tally type
a)
Note
Note
Note
