f INPUT 1 to 160 connectors
g OUTPUT 1 to 48 connectors
h OUTPUT 49 to 52 connectors
i FC OUTPUT 1
to 16 connectors
j SPARE 1 to 4
connectors
k MV OUTPUT 1
to 8 connectors
o U terminal
p MVS LAN connector
s RESET CIRCUIT BREAKER buttons
q UTL LAN connector
n - AC IN A, B, C, and D connectors
t REF IN connectors
XVS-8000
f INPUT 1 to 112 connectors
g OUTPUT 1 to 48 connectors
l SPARE 5 to 8 connectors
i FC OUTPUT 1
to 16 connectors
j SPARE 1 to 4
connectors
k MV OUTPUT 1
to 8 connectors
o U terminal
p MVS LAN connector
s RESET CIRCUIT BREAKER buttons
q UTL LAN connector
n - AC IN A, B, C, and D connectors
t REF IN connectors
XVS-7000
e M/E DEDICATED OUTPUT 1 to 16
connectors
d DEDICATED INPUT 1 to 16
connectors
