Technical specifications
Sophos AP 50
Chassis Plastic housing, white
Maximum theoretical throughput 300 Mbit/s
LAN interfaces 1 x 10/100/1000 Base-TX
Supported WLAN standards 802.11 a/b/g/n 2.4 GHz / 5 GHz
Antennas 2 x 2.4G/5G (3dBi/5dBi) dual-band antenna
Frequencies / channels Radio I: 11b/g/n: 2.412-2.472 GHz (ETSI) Channels 1-11
2.412-2.462 (FCC) Channels 1-11 (FCC)
Radio II: 11a/n: 5.180-5.240 GHz (ETSI / FCC) Channels 36, 40, 44, 48 (ETSI / FCC)
5.745-5.825 GHz (FCC) Channels 149, 153, 157, 161, 165 (FCC)
Power supply 100-240 VAC, 50/60 Hz, max. 0.3 A
Power consumption 9,6 W (800 mA/12 V)*
Power-over-Ethernet Yes (802.3at)
Dimensions 217 x 139 x 28 mm
Weight 390 g
Temperature range Operating: 0°C to 45°C Storage: -10°C
to 70°C
Humidity (non-condensing) 15% to 95%
Mounting Desktop / wall
Supported security standards WPA/WPA2, WEP, 802.1X (RADIUS)
Number of supported SSIDs 8
Regulatory compliance CE FCC MIC/VCCI (Japan)
Radio: EN 300328,
EN 301893
CFR 47, Part 15 Subpart C, E Certification ID:
201-140005
EMC: EN 301489-1,
EN 301489-17
EN 60601-1-2
(medical electrical
equipment)
CFR 47, Part 15 Subpart B V-3/2013.04
V-4/2012.04
EMF: EN 50385 FCC 1.1310, IEEE C95.1 N/a
Safety: EN 60950-1 N/a N/a
* It is recommended to only use PoE+ capable (IEEE 802.3at) equipment to power the Sophos AP 50.
