Technical specifications
PoE injector PD-3501/AC (AP 30) PoE injector PD-9001GR/AC (AP 50/AP 100)
Chassis Plastic housing Plastic housing
Input power AC input voltage: 90-264 VAC AC Input Voltage: 100 to 240 VAC
AC input current: 0.5 A, 100-240 VAC AC Input Current: 0.8A @ 100-240 VAC
AC frequency: 47/63 Hz AC Frequency: 50 to 60 Hz
Power-over-Ethernet output (max.) Output power voltage: 50 VDC Output power voltage: 55 VDC
Output power: 15.4 W Output power: 30 W
Supported PoE standard 802.3af compliant 802.3at compliant
Weight 200 g 200 g
Dimensions W x H x D 53 x 33 x 140 mm 1 x 10/100/1000 Base TX, plus 55 VDC
Mounting Desktop / wall Desktop / wall
Temperature 0°C to 40°C (operating) 0°C to 40°C (operating)
-20°C to 70°C (storage) -20°C to 70°C (storage)
Humidity (non-condensing) 10% to 90% 10% to 90%
Regulatory compliance CE, FCC, VCCI, UL, GS, RoHS, WEEE CE, FCC, VCCI, UL, GS, RoHS, WEEE
