Sophos AP6 Series User Manual

5AP6 420(E)/840(E)
Operating Instructions
Technical specifications
AP6 420
Environment
Power consumption 15W (max.)
Power over Ethernet
(PoE) requirements
802.3at
Operating temperature 0° to 40° C
Storage temperature -40° to 70° C
Humidity 10% to 95% non-condensing
Hazardous substances RoHS-2 and REACH compliant
Physical specification
I/O ports 1x Micro USB connector console serial port
1x RJ45 10/100/1000 Mbps Ethernet w/PoE (802.3at PD)
1x Reset button
1x Kensington security slot
1x 12V DC connector
Memory 1 GB DDR3L
4 MB NOR Flash
512 MB NAND Flash
Mounting Desktop
Wall-mount
Ceiling (15/16, 9/16 inch ceiling tracks)
Dimensions
(Width x Depth x Height)
183 x 183 x 35 mm (7.2 x 7.2 x 1.38 inches)
Weight 0.7 kg (1.54 lbs)
Wireless specification
Radios 1x 2.4 GHz single band
1x 5 GHz single band
Antennas 2x internal dual band antenna for Radio-1 (omni-directional)
2x internal 5 GHz antenna for Radio-2 (omni-directional)
Antenna Peak Gain 4.2 dBi at 2.4 GHz, 5.5 dBi at 5 GHz
MIMO capabilities 2x2:2
Supported WLAN standards IEEE 802.11 a/b/g/n/ac/ax
SSIDs 16 (8 per Radio)
Max. Throughput 575 Mbps (2.4 GHz) + 2400 Mbps (5 GHz)

Sophos AP6 Series Specifications

General

Wi-Fi Standard	Wi-Fi 6 (802.11ax)
MU-MIMO	Yes
Mounting	Wall or ceiling mount
Frequency Bands	2.4 GHz and 5 GHz
PoE Support	802.3at PoE
Security Features	WPA3
Antenna	Internal
MIMO	2x2 MIMO
Operating Temperature	0°C to 40°C
Ethernet Ports	1 x 1 GbE or 2.5 GbE (depending on the model)
