Sophos APX 320 Quick Start Guide

2Quick Start Guide APX 320/530/740
ENGLISH
For more information about your switch, scan the QR code or visit
www.sophos.com/get-started-ap
1. Before Deploying
Congratulations on the purchase of your Sophos APX Series access point. This Quick
Start Guide provides you with instructions to connect the access point and do the initial
configuration.
Before you begin, please make sure that you have access to one of the following products
which include the Sophos wireless controller needed to manage your Sophos access point:
Ì Sophos SG UTM
Ì Sophos Wireless (Sophos Central managed)
Ì Sophos XG Firewall
Please ensure you have a valid license for one of the above products.
To power and connect your access point you will need to have either a PoE injector
(available as an accessory from your Sophos partner) or a PoE switch plus an RJ45
Ethernet cable.

Sophos APX 320 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Frequency band	2.4 / 5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1743 Mbit/s
Antenna type	Internal
Antenna features	Integrated antenna
Antennas quantity	5
Antenna gain level (max)	6.7 dBi
Number of products included	1 pc(s)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	-
Number of SSID supported	16
Placement	Ceiling, Table, Wall
Certification	CB, UL, CE, FCC, ISED (IC), RCM, MIC, NCC, Anatel. EN 60601-1-2 UL2043
Product color	White
Cable lock slot type	Kensington
Power consumption (max)	11.5 W
Sustainability certificates	CE
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Internal memory	512 MB
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	38 mm
Width	155 mm
Weight	474 g
