Sophos APX 320 Quick Start Guide

6Quick Start Guide APX 320/530/740
ENGLISH
5. Access Point Reboot & Reset
Reboot with current image and configuration
1. Press reset button
2. Release reset button
3. AP reboots (LED will go off, then will turn to solid green)
Reboot with current image and clear configuration
1. Press and hold reset button
2. AP reboots (LED will go off and then switch to green briefly)
3. LED will turn solid red for 5 sec. You can still cancel the configuration clearance
process by releasing the reset button before the LED starts blinking
4. LED will blink red (configuration will be cleared)
5. Release reset button
6. AP reboots with factory default settings
Reset
Button
Status LED
Released
Pressed
Solid Solid Blinking
Reboot Reboot clear config
5 Sec
Off
6. Support and Documentation
For more information and technical support, please visit
www.sophos.com/en-us/support or contact your local Sophos reseller.

Sophos APX 320 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Frequency band	2.4 / 5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1743 Mbit/s
Antenna type	Internal
Antenna features	Integrated antenna
Antennas quantity	5
Antenna gain level (max)	6.7 dBi
Number of products included	1 pc(s)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	-
Number of SSID supported	16
Placement	Ceiling, Table, Wall
Certification	CB, UL, CE, FCC, ISED (IC), RCM, MIC, NCC, Anatel. EN 60601-1-2 UL2043
Product color	White
Cable lock slot type	Kensington
Power consumption (max)	11.5 W
Sustainability certificates	CE
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Internal memory	512 MB
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	38 mm
Width	155 mm
Weight	474 g
