7. Connecting Power over Ethernet (PoE) Devices
All ports on PoE-capable switches can provide Power over Ethernet (PoE) to a connected PoE device
which conforms with the 802.3af (max. 15.4W) or 802.3at (max.30W) standards. Each port can provide
up to a maximum of 30 Watts.
Please note: If the total power consumption of all PoE-powered devices exceeds the power budget of the
switch, the PoE Max LED will turn on. The port with the highest number and the lowest priority (according
to the per-port priority settings configured), will no longer receive power and the PoE Mode LED for that
port will be turned off.
To avoid such situations, Sophos recommends calculating the number of connected devices based upon
their max. power consumption (see table "interfaces" above).
8. LED Status
Status LEDs
Power Green Solid Power On
Off Power Off
Fault Amber Solid Error
Off Normal Behavior
PoE Max Amber Solid The power requested by PoE devices exceeds total PoE limit
of the switch. No additional devices can be powered.
Off Additional PoE devices may still be powered
LAN Mode
*
Green Solid The left LED on RJ45 ports indicates Speed
PoE Mode
*
Green Solid The left LED on RJ45 ports indicates PoE status
* By pressing the “LED mode” button you can switch the meaning of the left LED on each RJ45 port (labeled with “mode”) between LAN
Mode and PoE Mode.
ENGLISH
Quick Start Guide Sophos Switch Series

Sophos CS101-8 Specifications

General

Brand	Sophos
Model	CS101-8
Category	Switch
Language	English
