Introduction
These operating instructions will help you install and configure the Sophos RED
appliances and provide technical specifications of all RED devices. In addition,
please also see the following documents that contain useful information on safety
regulations, regulatory compliance, and configuration options:
Ì Sophos RED Appliances Safety Instructions & Regulatory
Information (part of the scope of supply)
Ì Sophos RED 15/50 Quick Start Guide (part of the
scope of supply depending on RED model)
Ì Sophos UTM Administration Guide
The instructions must be read carefully prior to using the device and should be kept
in a safe place. You may download all user manuals and additional documentation
from the Sophos Knowledgebase at http://www.sophos.com/en-us/support/
knowledgebase.aspx.
RED 15
Scope of supply
Installation
Preliminary steps
Make sure that the RED appliance has been shipped to the branch office. Ask the
person who is going to put the RED appliance into operation at the branch office to
provide the unique RED-ID, which is printed at the bottom of the device. Note that the
RED appliance requires a working Internet connection at your branch office.
Configuring the RED appliance
Configure the RED appliance in the central UTM appliance as described in the Sophos
UTM Administration Guide.
Product/ :
Model/ : RED 15 Rev.1
RED ID#
Manufactured:
December 2012
WAN MAC Address: 00:1A:8C:01:00:01
LAN MAC Address: 00:1A:8C:01:00:00
Input Rating/ : 12V 1.5A MAX (18W MAX)
Sophos Ltd
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions.
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
E324625
RJ45 Ethernet cableQuick Start Guide and
Safety Instructions
Sophos RED 15
Appliance
Power supply
