Sophos RED 50 Quick Start Guide Power supply Shielded RJ45
Appliance and Security Notes and cable Ethernet cable
Security Notes and
Regulatory Compliance
Sophos RED Appliances
Technical specifications
Sophos RED 10
Chassis Metal housing (painted white)
Mounting Desktop
Dimensions (W x H x D) 155 x 117 x 30 mm
Weight 510 g
Power supply Input: 100-240 V, 50/60 Hz, 0.5 A Output: 12 V
1 A
Power consumption 7 W (max.)
Operating temperature 0-40°C (operating), -20-65°C (storage)
Humidity 10-85% (operating), 5-95% (storage), non-condensing
Regulatory compliance
Safety
CE EN 60950-1:2006+A11:2009+A1:2010+A12:2011
CB IEC 60950-1:2005+A1:2009
EMC
CE EN 55022:2006+A1:2007
EN 55024:1998+A2:2003
EN 61000-3-2:2006+A2:2009
EN 61000-3-3:2008
FCC CFR 47, Part 15 (Class B), ANSI C63.4
C-Tick AS/NZS CISPR 22
VCCI VCCI V-3/2011.4 (CISPR 22:2008)
RED 50
Scope of supply
Installation
Preliminary steps
Make sure that the RED appliance has been shipped to the branch office.
Ask the person who is going to put the RED appliance into operation at the
branch office to provide the unique RED-ID, which is printed at the bottom
of the device. Note that the RED appliance requires a working Internet
connection at your branch office.
Quick Start Guide
RED 50
RED 50 Rev 1
WAN1 MAC Address:
WAN2 MAC Address:
3330mA
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
LISTED
E215284
I.T.E.
A0000014EE22E39
