5
B.1 Specifi cations
Electrical specifi cations:
Mains voltage 230VAC +/- 10%
Mains frequency 50...60Hz
Power consumption ~ 1.5VA
Switched power
- mechanic relay output R1 460VA for AC1 / 185W for AC3
- mechanic relay output R2 460VA for AC1 / 185W for AC3
Internal fuse 2A slow blow 250V
Protection category IP40
Protection class II
Sensor inputs 3 x Pt1000
Measuring range -40°C - 300°C
Permissible ambient conditions::
Ambient temperature
- for controller operation 0°C...40°C
- for transport/storage 0°C...60°C
Air humidity
- for controller operation max. 85% rel. humidity at 25°C
- for transport/storage no moisture condensation permitted
Other specifi cations and dimensions
Housing design 2-part, ABS plastic
Installation methods Wall installation
Overall dimensions 163mm x 110mm x 52mm
Aperture installation
dimensions 157mm x 106mm x 31mm
Display Fully graphical display, 128 x 64 dots
Operation 4 entry keys
Temperature sensors: (may not be included in the scope of supply)
Collector or boiler sensor Pt1000, immersion sensor TT/S2 up to 180°C
Storage tank sensor Pt1000, immersion sensor TT/S2 up to 180°C
Pipe-mounted sensor Pt1000, pipe-mounted sensor TR/S1.5 up to 180°C
Sensor leads 2x0.75mm² extendable up to 30m max.
Temperature resistance table for Pt1000 sensors
°C0 102030405060708090100
Ω 1000 1039 1077 1116 1155 1194 1232 1270 1308 1347 1385
Description of controller
