7
B.5 Hydraulic variants
Description of controller
Caution
The following illustrations should be viewed only as schematic dia-
grams showing the respective hydraulic systems, and do not claim to
be complete. The controller does not replace safety devices under any
circumstances. Depending on the specifi c application, additional system
components and safety components may be mandatory, such as check
valves, non-return valves, safety temperature limiters, scalding protec-
tors, etc., and must therefore be provided.
1
Solar with
storage
2
Solar with
pool
3
Solid fuel boiler
4
Storage transfer
5
Raising heat circuit
6
Thermo
stat
7
T Univer
sal
8 Stop valve
9
Solar with thermo
stat
10
Solar + Cooling
2x Thermostat
11
