8. Technical Data
Mode Power output into
[
Ω ]
Output range
[W]
Nominal
Frequency [kHz]
Output Volt.
[V
PP
]*
Cut 1
10W [200
Ω ]
1W 70W 350 820
Cut 2
70W [200
Ω ]
10W 130W 350 1160
Cut 3
130W [200
Ω ]
60W 210W 350 1240
Cut 4
210W [200
Ω ]
130W 320W 350 1290
Cut 5
320W [200
Ω ]
210W 320W 350 1320
Blend 1
10W [200
Ω ]
1W 60W 350 830
Blend 2
60W [200
Ω ]
10W 120W 350 1160
Blend 3
120W [200
Ω ]
60W 180W 350 1240
Blend 4
180W [200
Ω ]
120W 250W 350 1280
Blend 5
250W [200
Ω ]
180W 250W 350 1320
TUR1
10W [200
Ω ]
1W 70W 350 940
TUR2
70W [200
Ω ]
10W 150W 350 1250
TUR3
150W [200
Ω ]
70W 250W 350 1320
TUR4
250W [200
Ω ]
150W 350W 350 1320
TUR5
350W [200
Ω ]
250W 350W 350 1320
Pulse1
7W [200
Ω ]
1W 14W 350 1180
Pulse2
14W [200
Ω ]
7W 22W 350 1250
Pulse3
22W [200
Ω ]
14W 31W 350 1300
Pulse4
31W [200
Ω ]
22W 40W 350 1320
Pulse5
40W [200
Ω ]
31W 40W 350 1320
TUR-Pulse1
8W [200
Ω ]
1W 16W 350 1180
TUR-Pulse2
16W [200
Ω ]
8W 26W 350 1250
TUR-Pulse3
26W [200
Ω ]
16W 38W 350 1300
TUR-Pulse4
38W [200
Ω ]
22W 50W 350 1320
TUR-Pulse5
50W [200
Ω ]
38W 50W 350 1320
Soft 1
5W [200
Ω ]
1W 30W 350 320
Soft 2
30W [200
Ω ]
5W 55W 350 480
Soft 3
55W [200
Ω ]
30W 80W 350 620
Soft 4
80W [200
Ω ]
55W 100W 350 680
Soft 5
120W [100
Ω ]
80W 120W 350 680
*Output voltages are no load values
