Söring MBC-601 - Error Codes for Troubleshooting

27/04/04 © Söring Users manual RF-units
1
not valid for MBC600
-34-
Error codes
(Further data see service manual!!!)
If occurring problems can not be solved by the service technician in the hospital please call the Söring
Company at 682-531-0950and transmit the error code and the serial number of the unit!
Basically the error code is indicated in the left most 7-segment display. The indication is divided into the “function
group“(i.e.: 1) and the function (i.e.: 2), separated by a dot.
Code Description
1.1 external watchdog error
1.2 internal watchdog error
2.1 - 2.6 faulty idle measurement
3.1 - 3.3 reference voltage error
4.1 - 4.6 offset error
5.1 error on RF output board
6.1 - 6.3 error in power supply watchdog
7.1 - 7.8 power supply voltage too high or too low
8.1 - 8.2 defective handpiece recognition
9.1 - 9.4 defective patient electrode recognition
10.1 - 10.8 defective relays
11.1 - 11.6 see 4.1 - 4.6
12.1 - 12.7 Cut module defective
13.1 - 13.5 Coag module defective
Power supply data
Mains voltage:
Mains fuses:
Mains cable:
Potential
equalization:
Power consumption:
230V, 50Hz
Internally switchable to
115V, 60Hz
Built into main filter containing 2 fuses
T 4A/250V slow blowing according to IEC127 for 230V main voltage
Respectively T 8A/250V slow blowing for 115V main voltage
Length 2.5 m with protective conductor, mains part according to DIN
49 441 resp. CEE 7 p.VII,
Equipment part according to DIN 49 457 p.1.
Plug and socket vulcanized to cable. Cable has to fulfill accepted
norms and has to have a diameter of 1mm
.
Connector according to DIN
1000 VA
Classification
Safety class:
Safety grade:
Classification
Weight:
Dimensions:
WxHxD
Applied standards:
I
according to EN60601-1 CF
II b
601-er: 42 lbs. (19kg); 600-er: 41 lbs (18,5)kg
430mmx150mmx430mm
93/42/EWG, EN60601-1, EN60601-2-2
