4.2 Technical data
Type
SMS 150 / SMS 151
Mains voltage 230V AC / +-10% / 115V AC / +-10%
Mains frequency 50Hz / 60Hz
Output frequency 25Hz/50Hz / 30Hz/60Hz
Output voltage 30 - 228 V AC / 30 - 113 V AC
Setup to 200 VAC
Output current 0,01 - 6 A AC
Type of protection IP 54 at mounting hanging
(fitting show down)
Fuse 1 x 6,3 A F flink
Ambient temperature 0 .. 50°C
Setpoint Internal potentiometer
Mains connection 2m with gated Schuko-plug 90°
Connection conveyor 2m witht Contact HA3-BS plug
Housing Al-background + Al-Strand casting +
Plastic cover
Dimensions (l x b x h) ca. 175 x 80 x 94 mm
Features:
Oscillation frequency
Reversible
Controller input isolated
Switching level HI: 6 - 24 VDC
Switching level LO: 0 - 4 VDC
+24 V DC / max. 50mA / PNP
Opener mode:
Output voltage 0 V with applied
switching voltage of + 24 V DC
Preset output voltage with applied
switching of 0 V DC
Closer mode :
Output voltage 0 V with applied
switching voltage of 0 V DC
Preset output voltage with applied
switching voltage of + 24 V DC
Twin timer (GAN/GAB) GAN turn ON delay : 0-10 seconds
GAB turn OFF delay : 0-10 seconds
Soft-start t1
ca. 0.5 - 5 sec. Variable
Soft-stop t2
ca. 0.1 - 5 sec. Variable
Mains voltage compensation
(arithmetic measurement)
Compensation of mains voltage fluctu-
ations at output.
With preset output voltage of e.g.
170 V AC a max. voltage change of
3,5
V AC arises, with changes of the in-
put voltage from 230 V AC to 200 V AC
or from 230 V AC to 260 V AC.
Standards complied with DIN EN 50 081 Part 1
Residential, commercial and trade and
light industry, industry.
DIN EN 50 082 Part 2
Industry
VDE 0160
