SORVALL
®
CENTRIFUGES RT6000B and T6000B CENTRIFUGES
Serial Numbers Below 9101800
Table 8-5. Parts: T6000B (SN Below 9101800)
(keyed to figure 8-10) (continued)
ITEM P/N DESCRIPTION QTY.
34 67874 Velcro® Fastener, Hook 7 inches 1
35 60436 Louver, 14 Mesh, 3" diameter 2
36
07628
Lamp Holder Assembly, Door Open 1
37
67372
Lamp 1
38
67380
Relay, 24 Vdc. 50/60 Hz, 3 PDT, 3/16" Contacts 1
39
63085
Flatwasher, SST, 0.169 I.D. x 0.304 O.D. x 0.032" Thick 1
40
63011
Lockwasher, No. 6 2
41
60074
Nut, Hex, SST, No. 6 1
42
64877
Woodruff Key, 3/32 x 3/8" 1
43 07572 Support, Block Shaft 1
44
60023
Truarc® Retaining Ring, External, 1/4", SST 15-7 PH 4
45
61652
Flatwasher, No. 10 1
46 07642 Shield Assembly, Insulating, P.C. Board 1
47 67693
Receptacle, Fasteners, Treelok (Not available)
1
48 60674 Screw, Machine, Flat Head, 82o countersink, No. 6-32 x 3/8"
Long
6
49
61597
Screw, Machine, Pan Head, Slotted, SST, UNC., No. 6-32 x
5/16" Long
2
50
63085
Flatwasher, Steel Cad Plate, 0.169 I.D> x 0.304 O.D. x 0.032"
Thick
2
51 07641
Outter Assembly, Console (Not available)
1
52
07676
Knob Assembly, Latch Control 1
53
61682
Screw, Set, Hex Socket, Cup Poimt, Aly Steel Black Oxide, No.
8-32 x 7/16" Long
1
54
60522
Flatwasher, SST, 0.156 I.D. x 0.375 O.D. x 0.031 1
55
64771
Screw, Machine, Pan Head, Slotted, SST, No. 6-32 x 3/4" Long 1
56 67888 Screw, Machine, Pan Head, Slotted, Steel, Black Passivate,
UNC, No 6-32 x 1.25" Long (Not available)
1
57
67324
Foot 4
58
61258
Screw, Cap, Socket, Hex Head, SST, 1/4-20 x 5/8" Long 4
59
67378
Power Cord, 60 Hz, 125V, 15A OR 1
67823
Power Cord, 50 Hz, 250V, 10A 1
60
----- Antirotation Plate (Not available)
1
61
67828*
Fan Assembly, 115V, 60 Hz 1
07823
Fan Assembly, 220V, 50 Hz (Not available)
* Beginning in May 1992, 60Hz T6000B centrifuges can be retrofitted with a new harness that shuts the fan off
when the centrifuge is in standby (power ON but no run in progress). To retrofit a centrifuge, order update kit PN
12946.
Rev. 2/2002 8-44
