SORVALL
®
CENTRIFUGES RT6000B and T6000B CENTRIFUGES
Serial Numbers Below 9101800
Table 8-5. Parts: T6000B (SN Below 9101800)
(keyed to figure 8-10)
1
ITEM P/N DESCRIPTION QTY.
1 07524 Access Cover 1
2 07684 Seal, Cover, Insulation 2
3
67301
Transformer, Power 3
4
67351
Screw, Phillips, Colored, Pan Head, No. 8-32 x 3/8" Long 3
5
66665
Choke, Filter, 21 MH, ADC 1
6
63936
Lockwasher, External Tooth, No. 8. SST 1
7
67699
Receptacle, Plug, Three-Prong, 60 Hz, 15A, 250 Vac, OR 1
67379 Receptacle, Plug, Three-Prong, 50 Hz, 10A, 250 Vac 1
8
61095
Flatwasher, No. 4 2
9
63006
Lockwasher, Split, Steel, No. 4 2
10 60463 Nut, Hex, Steel, No. 4-40 2
11 67381 Insulation, Tape, Vinyl, Closed Cell Foam, 3/16 Thick x 3/8"
Thick
1
12
66643
Jack, Banana, Double Insulated, Miniature 1
13 67310 Insulaion, Tape, Vinyl, Closed Cell Foam, 1/8 Thick x 3/8"
Wide
1
14
67302
Hinge 2
15
67311
Lockwasher, Split, Black, No. 8 x .031 Thick 16
16 67312 Screw, Machine, Pan Head, Slotted, Black No. 8-32 x 3/8"
Long
16
17 67313 Screw, Machine, Flat Head, 82o countersink, Black No. 10-32
x 3/8" Long (Not available)
2
18
07809
Door Assembly 1
19
07583
Cover Assembly, Kydex® acrylic resin 1
20
07746
Door Seal 1
21
67852
Cap, Polyethylene, Black 4
22
61597
Screw, Machine, Pan Head, Slotted, SST, No. 10-32 x 3/8"
Long
47
23
63016
Lockwasher, Split, No. 10 x 0.040" Thick 40
24
67853
Washer, Steel, Zinc Plate, No. 10 4
25 67383 Flatwasher, Nylon,, 0.194 I.D. x 0.375 O.D. x 0,125" Thick 4
26 67875 Velcro® Fastener, Hookl, 7 inches 1
27 07636 Plate Assembly, Top, Frame, (left side) 1
28 07637 Plate Assembly, Top, Frame, (right side) 1
29
07638
Boot, Gyro 1
30
07556
Insulating Ring, Foam, Gyro 1
31 68838 Rubber Bumper (some T6000 Centrifuges were manufactured
with Temperature Sensor PN 07661) installed instead of
bumper)
1
32
07960
Bowl Assembly 1
33
07685
Seal, Latch 2
1
Rev. 2/2002 8-43
