SoundCraft Notepad 5 User Manual

3.0: INPUTS AND OUTPUTS
INPUTS, OUTPUTS, AND CONNECTIONS
3.0: INPUTS AND OUTPUTS
The physical inputs and outputs on the Notepad console are varied, and together with the mic
preampsandHi-Zinputcontrol,provideaexibleschemeforanysourcesyoumightencounter.Toget
the most out of the Notepad I/O, read this chapter carefully.
Console inputs can be used for a wide variety of sources. For best results always use the appropriate
input connection.
NOTEPAD 5, 8FX, 12FX User Manual
Analog Inputs
USB I/O
Analog Outputs
