5.1.3: FX RETURN CONTROLS
CHANNEL CONTROLS > FX RETURN CONTROLS
5.1.3: FX RETURN CONTROLS
Aux/FX send is pre-fade due to the dual use of the Aux bus. An
inputchannel’scontributiontothatAuxSendprocessingeldis
independent to that channel’s Level contribution to the main ste-
reo mix.
Notepad 8FX returns the effects directly to mix at unity.
Notepad 12FX stereo FX Return channel is a cut-down version of
the normal stereo channel without trim, EQ, or Aux sends.
An example in use might be running a Reverb algorithm in the
processor. Each individual channel’s Aux/FX rotary knob will
control how much of that source is summed with others, then pre-
sentedinthereverberanteldgeneratedbytheprocessor;theFX
return Level knob will then control the return level of that whole
reverberanteldintheMasterstereobusmix.
NOTEPAD 5, 8FX, 12FX User Manual
