E-2
LOCATION OF CONTROLS
Remote control
1. R-SPEAKERS 13. DISC COMPARTMENT OPEN/CLOSE
BUTTON
2. DISC COMPARTMENT; 14. VOLUME UP BUTTON
3. BASE; 15. VOLUME DOWN BUTTON
4. REMOTE SENSOR 16. SKIP UP, FAST FORWARD, TIME UP
BUTTON
5. L-SPEAKERS 17. FM ANTENNA
6. LCD -DISPLAY 18. AC SOCK
7. USB-JACK 19. AUDIO IN JACK
8. STAND BY BUTTON
9. SOURCE BUTTON
10. PLAY/PAUSE BUTTON
11. STOP BUTTON;
12. SKIP DOWN, FAST REVERSE, TIME
DOWN BUTTON
