Soundoff Signal 400 Series User Manual

ETCPRSP01 0718
1.800.338.7337 / www.soundoffsignal.com
Pg. 8
Allows the operator to have the siren automatically turn on auxiliary push-buttons based on the position
of the slide switch.
If an auxiliary push-button is programmed to turn ON when the slide switch position is selected,
the auxiliary push-button will turn OFF when the programmed slide switch position is no longer
selected.
The operator can override the automatic activation of the auxiliary push-button by momentarily
pressing the auxiliary push-button.
To program:
1. Press auxiliary push-buttons ‘4’ and ‘5’ for 2 seconds until Radio Rebroadcast indicator LED ashes.
2. Move slide switch to desired position.
3. Press auxiliary push-buttons ‘1’ – ‘8’, as required.
4. Repeat steps 2 and 3 for other slide switch positions as required.
5. Place appropriate button legend over activity indicator for each programmed button.
PARK KILL SETTINGS:
Press and Hold Auxiliary Button 1 and 3 until slide switch #3 LED ashes.
Enables auxiliary outputs to be disabled when Park Kill input is active. Auxiliary outputs can be
turned back on by pushing the buttons again.
LED ON
(GREEN)
Auxiliary push-button will automatically turn
ON when level switch position is activated.
LED OFF
(RED OR OFF)
Auxiliary push-button will NOT automatically
turn ON when level switch position is
activated.
2. SLIDE SWITCH ENABLED WITHOUT IGNITION: After ignition is turned off, device will stay
on in lower power mode and allow (ONLY the slider to operate.)
ON = With ignition off, slider relays will still turn on if slider is in
position 1, 2, or 3. Device will turn off if no ignition after 18
hours, or if battery is below 10.5V after 2 hours.
OFF = Device turns off normally, sliders will not work when off.
ALTERNATE MODES:
Press and Hold Auxiliary Button “2” and “6” until Slide Switch indicator #1 and indicator #2 LED
ashes.
1. DISABLE RELAY ERROR FOR AUX 7 & 8:
ON = Disable fault detect indication for Aux relays 7& 8.
OFF= Fault detect normal.
OTHER MODES:
Press and Hold Auxiliary Button “1” and “5” until slide switch #1 and #3 indicator LED ashes.
2. Power Down: Determines siren operation after ignition wire input has no voltage.
ON = Timed Power Down: Siren will power down 10 min. after last
activity.
OFF = Immediate Power Down: Siren will go into lowest power state
within 10 seconds.
1. Buzzer: Audible tone from control panel whenever operator presses push-button or changes
position of slide/rotary switch.
ON = Buzzer enabled.
OFF = Buzzer disabled.
3. 8 Second Buzzer alert: Provides audible beep whenever any auxiliary switches are ON or level
1,2, or 3 is active.
ON = Enabled.
OFF = Disabled.
SLIDE SWITCH MAPPING PROGRAMMING:
1. Park Kill Polarity Mode: Determines what voltage level will activate park kill functions.
ON = activated when +V is applied to Park Kill input wire.
OFF = activated when Ground is applied to Park Kill input wire.
2. Press the Radio Rebroadcast button to exit programming mode.
3. Push and hold Auxiliary Push-Buttons 2 & 3 until arrow indicator LEDs ash.
4. Press Push-Buttons 1-8 to toggle whether that auxiliary output will turn off when Park Kill input
becomes active. LED on means output will turn off.
5. Press the Radio Rebroadcast button to exit programming mode.
REMOTE CONTROL PANEL
ETCPRSP01 - 8 Button Controller w/ Radio Rebroadcast and Slide Switch
