43
Advanced Setup Table
Default = Factory Default Setting
Step# Description Pg# Range Default
36 4th Stage Deadband 27 0 - 10 Degrees 2
37 Minutes Between 1st and 2nd Stage 27 0 - 60 Minutes 2
38 Minutes Between 2nd and 3rd Stage 27 0 - 60 Minutes 2
39 Minutes Between 3rd and 4th Stage 27 0 - 60 Minutes 2
40 2nd StageTurnoff Point 27 Deadband, Setpoint Deadband
41 3rd StageTurnoff Point 27 Deadband, Setpoint Deadband
42 4th Stage Turnoff Point 27 Deadband, Setpoint Deadband
43 Minutes of Fan Purge 28 0 - 3:00, 15 min. increments 0
- 0 = off
44 Wired Sensor Type 30 Remote, Supply & Outdoor Remote
45 Control to Temp Source 31 Thermostat, Wired Remote*, Thermostat
Wireless Remote, Average of
Wireless Remotes, Average
Thermostat and Wired Remote*,
Average All Sensors. *Option
only if prior step = “Remote”
46 Wireless Remote to Use 31 list of wifi sensors currently first linked
linked to thermostat. *This step sensor in
only appears if prior step =
“Wireless Remote” list
47 Humidity Only With Heat 29 On, Off Off
48 Fan With Humidity Demand 29 Fan On, Fan Off Fan Off
49 Fan With Dehumidify Demand 29 Fan On, Fan Off Fan Off
50 Cool To Dehumidify 29 On, Off Off
51 Maximum Occ Dehum Overcool 29 0 - 5 Degrees 2
52 Maximum Unocc Dehum Overcool 29 0 - 20 Degrees 2
53 Reheat Operation W/Cool To Dehum. 29 On, Off Off
54 Fan Off Delay 28 0 - 120 Seconds 0
55 F/C 31 Fahrenheit (F), Celsius (C) F
56 Aux Output Polarity 32 Open, Closed Open
57 Aux Output 32 Time, Temperature, Time
External, Economizer
58 Aux Output Program Days 32 1 Day, 5/1/1 Day, 7 Day 1
59 Day Of Week To Program 32 Sunday - Monday (S - M) MTWTFSS
60 Aux Output Start Time 32 12am - 12am 7am
61 Aux Output Stop Time 32 12am - 12am 9pm
62 Copy 32 Yes, No No
63 Aux Output Temp Source 33 Thermostat, Outdoor, Remote
Remote
64 Aux Output Trigger Point Temp 33 0 - 120 Degrees 65
65 Comfort Recovery 28 On, Off Off
cont. next page
