South-Tek Systems N2Blast FPS-650 User Manual

FPS-650 and FPS-1250 South-Tek Systems
Version: 7
Revision Date: 9/6/19 Page 12 of 29
Optional Mounting Bracket Kit Procedures
1. All N
2
-BLAST
®
mounting holes and optional mounting bracket
holes are for ¼” screws/anchors.
2. All brackets must be installed in orientation as shown to work
correctly.
3. Install the cabinet-mounting brackets on the N
2
-BLAST
®
first with
the bolts/lock nuts that are provided.
4. Locate the wall-mounting bracket. It is an 18” bracket without the
rectangular cutouts and will need to be installed on the wall at the
desired height and level. The bracket has 16” center to center
holes so the unit can be mounted directly to studs. This bracket
will need to be mounted per the diagram below using appropriate
for your type of wall material (wood, sheet metal, masonry, etc.…).
Once the 18” bracket has been wall-mounted, this will allow the
12” bracket that is fastened to the top flange of the cabinet a
fixed anchor to hang from. See diagram as to how the angles are
to be oriented on the back of the cabinet vs the wall.
a. Use the supplied nuts and bolts to attach the upper 12”
bracket onto the top flange per the diagram.
b. Use the supplied carriage bolts and nuts to attach the 18”
lower bracket to the bottom flange, don’t overtighten the
nuts yet. After installing the system, you may want to
offset the bracket slightly, hence the rectangular slots.
5. Optional: if wall studs are not 16” center-to-center or you have the
need to reinforce the mounting area, a ½” or thicker board of
plywood is recommended to be installed prior to hanging the
system. Use best general practices to ensure that the wood and
system will be secure at its full weight and remember that it will
be vibrating from compressor running.
6. Once the mounting brackets are all in place, hang the N2 Blast
cabinet from the top bracket making sure it is centered.
a. The cabinet should have at least 4” on either side for
breathing/cooling purposes.
b. Do not install near heat source or where steam or water is
present. Damage to system or bodily harm may result as
well as voiding warranty.
Warning: Secure the N
2
-BLAST® to the wall at the top and bottom flanges.
Failure to do so could cause damage or bodily injury.
