South-Tek Systems N2Blast FPS-650 User Manual

FPS-650 and FPS-1250 South-Tek Systems
Version: 7
Revision Date: 9/6/19 Page 28 of 29
Compressor Motor Nameplate
Operation Instructions
For proper operation of the Internal Quick Fill Compressor, first switch the generator to
bypass mode using the 3-way ball valve mounted atop the unit. For the generator to be in
Bypass Mode the ball valve handle must be in the fully upright position.
Once generator is in Bypass Mode and the system is ready for filling, turn on the
compressor using the external disconnect. Once system is done filling, switch the
generator back to Normal Operation Mode by turning the ball valve handle horizontal.
After the generator is back in Normal Operation Mode, shut down the compressor with
the external disconnect.
HORSEPOWER: 1.9
RPM: 3450
PH: 1 HZ: 60
VOLTAGE: 120/240 VAC
AMB: 40°C
FR.: 56Y
ENCL.: DP
DUTY: CONT.
S.F.: 1.0
CODE: N
INS. CL.: F
F.L.A.: 15/7.5
BRG: BALL
DE: 6204DDU
ODE: 6203DDU
