2.3 Rear panel
Net S10mini rear panel provides a more diverse interface function, is as shown in figure 2-3
Fig. 2-3 Net S10mini rear panel
Net S10mini rear panel function of each interface is as shown in table 2-2
NO.
Description
Function
1
GNSS antenna interface I
Connect with GNSS antenna via cable
2
GNSS antenna interface II
Reserve GNSS antenna interface for dual antenna usage
3
UHF antenna interface
Connect with the UHF antenna
4
SIM card slot
SIM card slot for Micro SIM
5
3G/4G network antenna
Connect with 3G/4G network antenna
Tab. 2-2 Net S10mini rear panel functions
①
②
③
④
⑤
