16
Specifications
Battery Replacement
To avoid electric shock, do not operate your meter
until the battery and fuse covers are in place and fastened securely.
To avoid electric shock, remove the test leads from
the meter before removing the battery cover.
WARNING:
WARNING:
15
Operation cont.
1. When the battery is depleted, the symbol will appear on the LCD
display. Replace the battery immediately.
2. Ensure the meter is turned off.
3. Use a small phillips screwdriver to loosen the one screw retaining the
battery cover.
4. Remove the battery cover.
5. Replace the batteries with two new AAA batteries.
6. Observe proper polarity as shown inside battery compartment.
7. Install the battery cover and tighten the screw. Do not overtighten the
screw.
Function
Range Resolution
Accuracy
(% of reading)
20.00A
200.0A
All ranges are specified for a sinewave from 10% to 100% of range
Bandwidth: 50Hz to 60Hz
2.000V
20.00V
200.0V
600V
All ranges are specified for a sinewave from 10% to 100% of range
Bandwidth: 45Hz to 400Hz
200.0mV
2.000V
20.00V
200.0V
600V
All ranges are specified from 10% to 100% of range
200.0Ω
2.000kΩ
20.00kΩ
200.0kΩ
2.000MΩ
20.00MΩ
All ranges are specified from 10% to 100% of range
10mA
0.1A
1mV
10mV
0.1V
1V
0.1mV
1mV
10mV
0.1V
1V
0.1Ω
1Ω
10Ω
100Ω
1kΩ
10kΩ
±(2.5% +9 digits)
±(1.5% +5 digits)
AC Voltage
(Autoranging)
DC Voltage
(Autoranging)
NOTE: Accuracy is stated at 64°F to 82°F (18°C to 28°C) and less than 75% RH.
AC Current
Resistance
(Autoranging)
±(1.0% +8 digits)
±(1.0% +3 digits)
±(1.5% +3 digits)
±(1.2% +3 digits)
±(1.0% +3 digits)
±(1.2% +3 digits)
±(3.0% +5 digits)
