SOYO SY-6BA+ Quick Start Guide

SY-6BA+ Quick Start Guide
7
Hardware
Installation
Step 2. Make Connections to the Mainboard
This section tells how to connect internal peripherals and power supply to the mainboard.
Internal peripherals include IDE devices (HDD, CD-ROM), Floppy Disk Drive, Chassis Fan,
Front Panel Devices (Turbo LED, Internal Speaker, Reset Button, IDE LED, and KeyLock
Switch.), Wake-On-LAN card, VGA card, Sound Card, and other devices.
For more details on how to connect internal and external peripherals to your new SY-6BA+
Mainboard, please refer to SY-6BA+ Mainboard User's Guide and Technical Reference
online manual on CD-ROM.
Connectors and Plug-ins
PCI Audio Card Header: SB-Link™ Wake-On-LAN Header: JP44
Connect the SB-Link™ cable from your
creative sound blaster PCI audio card to
this header.
Connect the WOL cable from your LAN
card to JP44.
CPU Cooling Fan: CPUFAN Chassis Fan: CHAFAN
Connect the CPU cooling fan cable to the
CPUFAN power connector.
Connect the case cooling fan cable to the
CHAFAN power connector.
USB TB LED SPK
Plug your USB devices
to this connector.
Connect your Turbo LED
cable to this header.
Connect the speaker cable to
this header.
RESET IDE LED KB-LOCK
Connect the reset button
to this heder.
Connect the IDE device
LED to this header.
Connect the Power LED and the
KB Lock switch to this header.
rDA (Infrared Device Header): IR1
Connect the cable from your IrDA device to this header.
I
ATX Power On/Off: PWRBT
ATX Power Supply: ATX PW
Connect your power switch to this
header (momentary switch type).
To turn off the system, please press
this switch and hold down for
longer than 4 seconds.
Attach the ATX Power cable to this connector
When using the Keyboard Wake-Up function,
please make sure the ATX power supply can
take at least 720mA load on the 5V Standby
lead (5VSB) to meet the standard ATX
specifications.
