Motherboard Description
SY-K7VEM+
6
A ATX Power Supply Connector
B COM2 Serial Port
C CPU Cooling Fan Connector
D Chipset Fan Connector
E Socket 462 Connector
F VIA VT8361 North Bridge chip
G DIMM Banks
H CPU FSB Selection
I Floppy Disk Drive (FDD) Port
J Bus Mastering E-IDE/ATAPI Ports
K Flash BIOS
L Front panel connectors
M VIA 82C686B South Bridge chip
N 16-bit ISA Slot
O 3V Lithium Battery
P Wake-On-LAN (WOL) Header
Q 32-bit PCI Mastering Slots
R CMOS Clear Jumper
S CD In Connector
T AC97 Codec Chip
U Serial Infrared (IrDa) Device Header
V Bank panel Connector
