Charging Test
Please choose "Charging Test" and press Enter key, select 12V or 24V from next screen to
choose correct charging system test.
NOTE: Do not shut down the engine during the test. Do the steps according to the following
instructions.
After the test finished, tester displays the effective charging voltages, ripple voltage and
charging test result.
NOTE: If no increase rev detected, it shall be the fault of generator regulator or connection
with battery failed. Tester will try 3 times to further detect, if still failed, it will skip the increase
rev detect and the test result displays "No Output". See below:
Check the connection between generator and battery, then retest.
