Space Pak CSOLSTICE SIM-036 User Manual

– 45 –
SIM Inverter Monobloc Air-to-Water Heat Pump
Address Function HEX Number Content Description Remark
2025 03 7E9 Reserved
2026 03 7EA Reserved
2027 03 7EB Reserved
2028 03 7EC Reserved
2029 03 7ED Reserved
2030 03 7EE Reserved
2031 03 7EF Reserved
2032 03 7F0 Reserved
2033 03 7F1 Reserved
2034 03 7F2 S01~S08 Switch status
bit0: S01 high pressure switch (0-close/1-open)
bit1: S02 Low pressure switch (0-close/1-open)
bit2: S03 Water ow switch (0-close/1-open)
bit3: S04 Emergency input (0-close/1-open)
bit4: S05 Mode switch (0-close/1-open)
bit5: Reserved
bit6: S07 Electric heating overload switch (0-close/1-open)
2035 03 7F3 Reserved
2036 03 7F4 Reserved
2037 03 7F5 Reserved
2038 03 7F6 Reserved
2039 03 7F7 Reserved
2040 03 7F8 Reserved
2041 03 7F9 Reserved
2042 03 7FA Reserved
2043 03 7FB Reserved
2044 03 7FC Reserved
2045 03 7FD T01 Inlet water temperature TEMP1
2046 03 7FE T02 Outlet water temperature TEMP1
2047 03 7FF T03 Exhaust temperature TEMP1
2048 03 800 T04 Tank temperature TEMP1
2049 03 801 T05 Suction temperature TEMP1
2050 03 802 T06 Coil temperature TEMP1
2051 03 803 T07 Ambient temperature TEMP1
2052 03 804 T08 Suction pressure TEMP1
2053 03 805 T09 Exhaust pressure TEMP1
2054 03 806 T10 Actual frequency DIGI1
2055 03 807 T11 Set frequency DIGI1
2056 03 808 T12 DC fan 1 speed DIGI1
2057 03 809 T13 DC fan 2 speed DIGI1
2058 03 80A T14 Suction overheat TEMP1
2059 03 80B T15 Exhaust overheat TEMP1
2060 03 80C T16 Module temperature protection value TEMP1
2061 03 80D T17 AC input voltage value DIGI1
2062 03 80E T18 AC input current value TEMP1
2063 03 80F T19 Effective value of phase current of compressor TEMP1
2064 03 810 T20 Main wire voltage value DIGI1
2065 03 811 T21 IPM/PIM module actual temperature TEMP1
2066 03 812 Mute display icon position Fan status sign bit8, Permanent exit timed mute sign bit9
2067 03 813 T22 DC fan target speed DIGI1
2068 03 814 T23 Target temperature after compensation TEMP1
2069 03 815 Reserved
2070 03 816 Reserved
2071 03 817 Reserved
2072 03 818 Reserved
2073 03 819 Reserved
2074 03 81A Reserved
2075 03 81B Reserved
2076 03 81C Reserved
2077 03 81D Reserved
2078 03 81E Reserved
2079 03 81F Reserved
2080 03 820 Reserved
2081 03 821 Reserved
2082 03 822 Reserved
2083 03 823 Reserved
2084 03 824 Reserved
