SIM Inverter Monobloc Air-to-Water Heat Pump
Specication
Test Condition (AHRI 550/590)
* Heating:
Ambient Temperature: (DB/WB): 45°F/43°F
Supply Water Temperature, 95°F, Return, 86°F
** Cooling:
Ambient Temperature, 86°F
Supply Water Temperature, 50°F, Return, 59°F
*** IPLV is the recognized measurement for Integrated Part Load Values in accordance with AHRI 550/590.
Ambient Temp = 95°F, delivered water Temp= 44°F. (2.4 GPM per 12,000 BTU/hr nominal capacity.
SIM Air-to-Water Heat Pumps modulate capacity based upon inlet water temperature. Temperatures shown above are the
temperature of the water returning from the system to the heat pump. Leaving water temperature will vary according to load.
Refer to the following performance charts to see the expected.
Units SIM-036 SIM-060
Cooling
Capacity Range** BTU/hr 12,704 - 34,423 17,884 - 59,523
Efciency Range** EER 11.74 - 11.26 11.26 - 10.75
Efciency*** IPLV 12.2 12.1
Delivered Water Temp Range DegF 41-68
Ambient Temp Range DegF 50-110
Heating
Capacity Range* BTU/hr 13,191 - 38,755 25,413 - 70,666
Efciency Range* COP 5.01 - 4.04 4.67 - 3.69
Delivered Water Temp Range DegF 60-130
Ambient Temp Range DegF 5-109
Electrical
Power V/Ph/Hz 230/1/60
Fan Motor A (QTY) 0.8 0.8 (x2)
Maximum Running Current A 18 21
Compressor Motor A 14 25
Max Fuse/Circuit Breaker/MOPD A 30 50
MCA A 24 35
SCCR kA 5 5
Refrigerant
Type R410A
Factory Charge lbs 5.29 7.06
Normal Pressure Low Side PSIG 305
Normal Pressure High Side PSIG 638
Fan
Quantity 1 2
Power Input W 200
Type EC
Max Speed RPM 750
Sound (@3meters) Maximum dBA 54 58
Hydronic
Rated Flow GPM 7 13
Max Water Temp (return) DegF 122
Piping Connections inch 1 1 1/4
Rated Pressure Drop PSI (ft W.C.) 6/13.8 10/23
Compressor
Type Rotary
Speed Range HZ 30-90
Quantity 1
Dimensions
Net Dimensions (L x W x H) inch 38.6 x 18.3 x 35.4 39 x 13 x 52
Shipping Dimensions (L x W x H) inch 40.9 x 19.3 x 36.2 42 x 18 x 53
Net Weight lbs. 242.5 326
Shipping Weight lbs. 271 368
