SIM Inverter Monobloc Air-to-Water Heat Pump
Performance
(all data based on pure water)
SIM-060 HEATING
SIM-060 COOLING
30 40 50 60 70 80 90
Heating Capacity 25,413 33,560 41,703 49,847 56,789 63,728 70,666
BTU/hr
COP 4.67 4.58 4.53 4.49 4.12 3.87 3.69
Heating Capacity 18,928 26,847 34,765 42,680 47,895 53,110 58,321
BTU/hr
COP 3.95 3.80 3.72 3.67 3.32 3.08 2.91
Heating Capacity 15,309 21,275 27,239 32,348 37,912 43,475 49,099
BTU/hr
COP 3.10 2.96 2.87 2.80 2.65 2.55 2.47
Heating Capacity 11,690 15,703 19,713 23,727 28,557 33,389 38,219
BTU/hr
COP 2.08 2.08 2.07 2.07 2.05 2.01 1.96
30 40 50 60 70 80 90
Heating Capacity 21,973 30,116 38,263 46,407 52,830 59,250 65,673
BTU/hr
COP 3.65 3.53 3.47 3.43 3.24 3.11 3.01
Heating Capacity 17,748 25,666 33,584 41,502 46,898 52,297 57,693
BTU/hr
COP 2.95 3.01 3.05 3.07 2.88 2.74 2.64
Heating Capacity 14,891 20,799 26,707 32,144 37,222 44,161 47,376
BTU/hr
COP 2.50 2.40 2.33 2.28 2.18 2.21 2.06
Heating Capacity 12,034 15,932 19,830 23,731 26,727 29,724 32,720
BTU/hr
COP 2.00 1.87 1.80 1.75 1.64 1.56 1.50
30 40 50 60 70 80 90
Heating Capacity 18,150 26,294 34,441 42,584 48,004 53,427 -
BTU/hr
COP 2.80 2.67 2.61 2.57 2.50 2.45 -
Heating Capacity 12,058 19,748 27,437 35,130 45,045 50,465 -
BTU/hr
COP 2.50 2.28 2.20 2.15 2.17 2.20 -
Heating Capacity 9,78215,519 21,256 24,389 28,017 31,642 35,270
BTU/hr
COP 1.45 1.47 1.48 1.49 1.55 1.59 1.63
Heating Capacity 7,50511,290 15,075 18,860 22,942 27,021 31,099
BTU/hr
COP 1.13 1.13 1.13 1.13 1.19 1.24 1.28
36°F DB,
34°F WB
19°F DB,
18°F WB
5°F DB,
3°F WB
19°F DB,
18°F WB
5°F DB,
3°F WB
Ambient
Temp.
Compressor
Frequency
Return water temperature, 122°F, supply water temperature 131°F
45°F DB,
43°F WB
5°F DB,
3°F WB
Ambient
Temp.
Compressor
Frequency
Return water temperature:104°F, supply water temperature:113°F
45°F DB,
43°F WB
36°F DB,
34°F WB
Ambient
Temp.
Compressor
Frequency
Return water temperature: 86°F, supply water temperature: 95°F
45°F DB,
43°F WB
36°F DB,
34°F WB
19°F DB,
18°F WB
0
12,000
24,000
36,000
48,000
60,000
72,000
20 30 40 50 60 70 80 90 100
Capacity, BTU
Compressor Frequency
SIM-060 Heat Capacity 86F RWT
45F DB,
43F WB
36F DB,
34F WB
19F DB,
18F WB
5F DB,
3F WB
0
12,000
24,000
36,000
48,000
60,000
72,000
20 30 40 50 60 70 80 90 100
Capacity, BTU
Compressor Frequency
SIM-060 Heat Capacity 104F RWT
45F DB,
43F WB
36F DB,
34F WB
19F DB,
18F WB
5F DB,
3F WB
0
12,000
24,000
36,000
48,000
60,000
72,000
20 30 40 50 60 70 80 90 100
Capacity, BTU
Compressor Frequency
SIM-060 Heat Capacity 122F RWT
45F DB,
43F WB
36F DB,
34F WB
19F DB,
18F WB
5F DB,
3F WB
1.00
2.00
3.00
4.00
5.00
20 30 40 50 60 70 80 90 100
COP
Compressor Frequency
SIM-060 Heat COP 86F RWT
45F DB,
43F WB
36F DB,
34F WB
19F DB,
18F WB
5F DB,
3F WB
1.00
2.00
3.00
4.00
5.00
20 30 40 50 60 70 80 90 100
COP
Compressor Frequency
SIM-060 Heat COP 104F RWT
45F DB,
43F WB
36F DB,
34F WB
19F DB,
18F WB
5F DB,
3F WB
1.00
2.00
3.00
4.00
5.00
0102030405060708090100
COP
Compressor Frequency
SIM-060 Heat COP 122F RWT
45F DB,
43F WB
36F DB,
34F WB
19F DB,
18F WB
5F DB,
3F WB
30 40 50 60 70 80 90
Cooling Capacity 14,915 26,724 32,389 34,915 41,366 45,973 49,591
BTU/hr
EER9.83 9.93 10.07 10.04 9.78 9.39 9.04
Cooling Capacity 14,847 26,621 32,321 34,813 41,297 45,905 49,489
BTU/hr
EER9.28 9.69 9.90 9.949.52 8.98 8.84
Cooling Capacity 14,744 26,485 32,185 34,642 41,161 45,734 49,318
BTU/hr
EER9.04 9.49 9.73 9.399.04 8.77 8.63
Cooling Capacity 14,676 26,280 32,082 34,574 40,990 45,598-
BTU/hr
EER8.57 9.15 9.49 8.988.84 8.23 -
30 40 50 60 70 80 90
Cooling Capacity 17,884 31,741 38,874 41,912 49,625 55,154 59,523
BTU/hr
EER 11.26 11.54 11.60 11.47 11.33 11.16 10.75
Cooling Capacity 17,816 31,946 38,772 41,297 49,557 55,086 58,021
BTU/hr
EER 10.89 11.26 11.30 11.19 10.75 10.34 10.07
Cooling Capacity 17,679 31,775 38,635 41,570 49,386 54,881 57,338
BTU/hr
EER 10.00 10.12 10.35 10.30 9.97 9.73 9.52
Cooling Capacity 17,611 28,123 37,202 41,502 49,181 54,710-
BTU/hr
EER8.91 9.39 9.73 9.399.15 8.87 -
Return water temperature: 59°F, supply water temperature: 50°F
86°F DB
95°F DB
Ambient
Temp.
Compressor
Frequency
Return water temperature: 46°F, supply water temperature 37°F
86°F DB
95°F DB
104°F DB
104°F DB
113°F DB
113°F DB
Ambient
Temp.
Compressor
Frequency
0
10,000
20,000
30,000
40,000
50,000
60,000
20 30 40 50 60 70 80 90 100
Capacity, BTU
Compressor Frequency
SIM-060 Cooling Capacity 45F RWT
86F DB
95F DB
104F DB
113F DB
0
10,000
20,000
30,000
40,000
50,000
60,000
20 30 40 50 60 70 80 90 100
Capacity, BTU
Compressor Frequency
SIM-060 Cooling Capacity 59F RWT
86F DB
95F DB
104F DB
113F DB
8.00
9.00
10.00
11.00
12.00
20 30 40 50 60 70 80 90 100
EER
Compressor Frequency
SIM-060 Cooling EER 45F RWT
86F DB
95F DB
104F DB
113F DB
8.00
9.00
10.00
11.00
12.00
13.00
14.00
20 30 40 50 60 70 80 90 100
EER
Compressor Frequency
SIM-060 Cooling EER 59F RWT
86F DB
95F DB
104F DB
113F DB
Water temperatures shown in the following tables are controlled by the Heating Target Temperature Set point. This is the temperature
of the water returning to the heat pump from the system. The supply water temperature will be higher than the Return Target
Temperature. Settings that will result in supply Temperature in excess of 131°F are not recommended and cannot be expected to be
achieved under all conditions.
Water temperatures shown in the following table(s) are controlled by the Cooling Target Temperature Set point. This is the temperature
of the water returning to the heat pump from the system. ("INLET" temperature on the home screen) The supply water temperature
("OUTLET" temperature on the home screen) will be lower than the Return Target Temperature. Settings that will result in the supply
temperature below 37°F are not recommended and cannot be expected to be achieved under all conditions.
