Operation
1-13
Re-install the bladder into the cuff wrap in reverse order. Make certain that all folds in the bladder
have been removed, and that the long end of the bladder fits into the long end of the cuff (see the
figure below).
!
• The cuff hose can exit from either opening in the cuff, depending on whether you
plan a right arm or left arm application.
ARTERY
BLADDER
(shown inserted into cuff wrap
for left arm application)
OPENING FOR
RIGHT ARM
OPENING FOR
LEFT ARM
