Spacelabs 90207 - Control and Data Symbols

Symbols
1-3
ENTER Key PRINT REPORT Key
Attention - Consult Operations or
Service Manual for Description
Risk of Explosion if Used in the
Presence of Flammable Anesthetics
Indicator — Remote control Indicator — Local Control
Return Unit to Monitor Mode Indicator — Out of Paper
Activate Recorder for Graphics Recorder Paper
Indoor Use Only Auto Mode (NIBP)
Output No Output (Terminated)
Data Input/Output HELP (Explain Prior Screen) Key
Clock/Time Setting Key Input/Output
Monitor Setup
Select Program Options
Set Initial Conditions Menu
Access Special Function Menu Normal Screen
Return to Prior Menu TREND/TIMER Key
Symbol Description Symbol Description
!
