SpacePak SIM-036 - Page 46

– 46 –
Inverter Air-to-Water Heat Pump
Order Code Description SIM-036 SIM-060
45W33-WG1194-01
Compressor
x
45W33-WG1259-01 x
45W41-WG1196-01
Access Panel
x
45W41-WG1196-02 x
45W19-WG1197-01 Access Panel Handle x x
45W43-WG1198-01
Fan Guard
x
45W43-WG1198-02 x
45W41-WG1199-01
Left Coil Guard
x
45W41-WG1199-02 x
45W34-WG1200-01 Fan Blade x x
45W31-WG1202-01 Fan Motor x x
45W41-WG1204-01
Rear Coil Guard
x
45W41-WG1204-02 x
45W41-WG1206-01
Electrical Box Cover
x
45W41-WG1206-02 x
45W41-WG1207-01
Top Cover
x
45W41-WG1207-02 x
45W50-WG1208-01 Finned Tube Coil x
45W50-WG1209-01 Refrigerant To Water Heat Exchanger x
45W11-WG1211-01 Flow Switch x x
45W11-WG1212-01 Pressure Sensor x x
45W41-WG1213-01
Rear Panel
x
45W41-WG1213-02 x
45W05-WG1216-01 Electrical Cover x x
45W41-WG1217-01
Side Panel
x
45W41-WG1217-02 x
45W11-WG1218-01 Low Pressure Switch x x
45W11-WG1218-02 High Pressure Switch x x
45W28-WG1219-01
EEV
x
45W28-WG1219-02 x
45W28-WG1220-01
Reversing Valve
x
45W28-WG1220-02 x
45W09-WG1224-01 Two-Pole Terminal x x
45W09-WG1225-01 Four Pole Terminal x x
45W10-WG1227-01 Relay x x
45W09-WG1228-01
EMI Reactor
x
45W09-WG1228-02 x
45W09-WG1229-01 Fan Speed Control x
45W09-WG1230-01
EMI Inverter Filter
x
45W09-WG1230-02 x
45W09-WG1231-01
Inverter Compressor Drive
x
45W09-WG1231-02 x
45W09-WG1232-01 Control Board x x
45W09-WG1233-01 Remote Display x
x
45W09-WG1261-01 Finned Tube Coil x
45W50-WG1262-01 Water To Refrigerant Heat Exchanger x
SIM Parts
